Compact Built-In Wine Cellar

SKU: SCR312LBICSSWC2

Tints
Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.
Commercial meets nsf
This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

Unique design lets you store bottles horizontally and upright

26.13" H x 17.75" W x 20.25" D

(66cm H x 45cm W x 51cm D)

OVERVIEW

  • Commercially listed to NSF-7 standards
  • Versatile interior lets you store red or white wine upright or horizontally on wooden shelves
  • Flexible design allows built-in or freestanding use
  • Factory installed lock provides security you can count on
  • Digital thermostat with external readout for easy and precise temperature control
  • Interior LED lighting for an elegant display with energy efficiency
  • Wrapped stainless steel cabinet offers durable luxury for any setting

SPECIFICATIONS

Overview
Height of Cabinet 25.5" (65 cm)
Height to Hinge Cap 26.13" (66 cm)
Width 17.75" (45 cm)
Depth 20.25" (51 cm)
Depth with Handle 22.0" (56 cm)
Depth with door at 90° 36.25" (92 cm)
Capacity 2.5 cu.ft. (71 L)
Bottles 22 bottles
Defrost Type Automatic
Door Glass
Cabinet Stainless Steel
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 80.0 lbs. (36 kg)
Shipping Weight 83.0 lbs. (38 kg)
Estimated Time to Ship 3 to 5 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Wine Cellar
Number of Zones 1
Door Swing RHD
Reversible No
Adjustable Shelves Yes
Shelf Type Wood
Shelf Qty 4
Thermostat Type Digital
Interior Light Yes
Refrigerant Type R134a
Refrigerant Amount 1.82 oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Height 1 20.5" (52 cm)
Interior Width 1 13.5" (34 cm)
Interior Depth 1 14.75" (37 cm)
Compressor Step Height 7.5" (19 cm)
Compressor Step Width 13.5" (34 cm)
Compressor Step Depth 5.25" (13 cm)
Temperature Range 40º to 72ºF

AVAILABLE UPGRADES

Door
T1 Door Tint
Tinted door in low-E mirror finish for maximum energy savings
T1S Door Tint
Reflective door tint in dark smoke finish for maximum energy savings
T2 Door Tint
Tinted door in reflective deep blue finish with high energy savings
T3 Door Tint
Reflective door tint in light blue finish for medium energy savings
T4 Door Tint
Neutral door tint in light smoke finish for moderate energy savings
Exterior
Extra key
Extra keys available for purchase
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

WHERE TO BUY

Invalid Format

DESCRIPTION

SUMMIT's SCR312LBICSSWC2 is a perfectly sized wine cellar with elegant construction that offers the ideal storage and sale conditions for wine.

This compact unit features a front-breathing system that allows built-in installation, while the fully finished cabinet also enables freestanding use on countertops. A stainless steel trimmed glass door includes a factory installed lock for convenient security and a pro style handle. This unit comes with a fully wrapped stainless steel cabinet.

Inside, the SCR312LBICSSWC2 is designed to store up to 22 standard 750ml "Bordeaux" style bottles of wine (or a combination of 18 wider "Burgundy" style bottles and 3 Bordeaux). It includes four wooden shelves and a metal insert that lets you stack bottles on the floor of the unit. Bottles can also be stored upright in front of the shelving, maximizing capacity and offering a great solution to keeping open bottles refrigerated. The SCR312LBICSSWC2 features a digital thermostat for easy temperature management and recessed LED lighting for an efficient, attractive presentation.

This unit is ETL-S listed to NSF-7 standards for commercial use.

FEATURES

Commercially approved
ETL-S listed to NSF-7 commercial standards
Built-in or freestanding capable
Front-breathing system allows the unit to be used built-in, while the finished cabinet also allows freestanding use
Double pane tempered glass door
Heat resistant design provides clear view of stored products
Factory installed lock
Keyed lock offers convenient security
22 bottle capacity
Interior can hold up to 22 standard 750ml Bordeaux style bottles. If using this wine cellar for wider Burgundy/Pinot Noir bottles, you can store up to 18 of those bottles with an additional 3 Bordeaux bottles.
Stainless steel wrapped cabinet
Durable design with lasting elegance
Professional handle
Stainless steel handle offers a professional look
Automatic defrost
Reduced user maintenance with auto defrost system
Digital thermostat
Precise temperature management with easy electronic controls and a digital display
Interior LED light
Externally located button turns this light on and off to illuminate the products for a tempting view
Wooden shelving
Four wooden shelves offer the perfect conditions for storing bottles horizontally
Vertical storage
3 bottles can be stored upright in front of the shelves, an ideal solution for keeping open bottles of wine refrigerated
Floor insert
Metal holder lets you lay 3 Bordeaux bottles or 2 Burgundy bottles safely on the floor
100% CFC free
Environmentally friendly design does not contain ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 25.5" (65 cm)
Height to Hinge Cap 26.13" (66 cm)
Width 17.75" (45 cm)
Depth 20.25" (51 cm)
Depth with Handle 22.0" (56 cm)
Depth with door at 90° 36.25" (92 cm)
Capacity 2.5 cu.ft. (71 L)
Bottles 22 bottles
Defrost Type Automatic
Door Glass
Cabinet Stainless Steel
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 80.0 lbs. (36 kg)
Shipping Weight 83.0 lbs. (38 kg)
Estimated Time to Ship 3 to 5 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Wine Cellar
Number of Zones 1
Door Swing RHD
Reversible No
Adjustable Shelves Yes
Shelf Type Wood
Shelf Qty 4
Thermostat Type Digital
Interior Light Yes
Refrigerant Type R134a
Refrigerant Amount 1.82 oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Height 1 20.5" (52 cm)
Interior Width 1 13.5" (34 cm)
Interior Depth 1 14.75" (37 cm)
Compressor Step Height 7.5" (19 cm)
Compressor Step Width 13.5" (34 cm)
Compressor Step Depth 5.25" (13 cm)
Temperature Range 40º to 72ºF

AVAILABLE UPGRADES

Door
T1 Door Tint
Tinted door in low-E mirror finish for maximum energy savings
T1S Door Tint
Reflective door tint in dark smoke finish for maximum energy savings
T2 Door Tint
Tinted door in reflective deep blue finish with high energy savings
T3 Door Tint
Reflective door tint in light blue finish for medium energy savings
T4 Door Tint
Neutral door tint in light smoke finish for moderate energy savings
Exterior
Extra key
Extra keys available for purchase

DOWNLOADS

Download
BROCHURE w/ DRAWINGS
SCR312LBICSSWC2.pdf
Download
TECHNICAL DRAWING (.dwg)
SCR312LBI_BEV.CENTER__A-C_2000_.dwg
Download
MSDS INFORMATION
MSDS_R134a___C.pdf
Download
SUPPORT
SCR312WC2.pdf
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
