VC28S

Delivery 9240a3e8870753a2ec143c34af2b405742ae73bfeb126dd29f201daa25ab8f11
This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.

18.13" H x 23.25" W x 22.13" D

(46cm H x 59cm W x 56cm D)

OVERVIEW

  • Double pane tempered glass door protects your collection from harmful light
  • Digital controls offer easy and intuitive temperature management
  • Seamless stainless steel trimmed glass door for true luxury
  • Recessed LED lighting offers an elegant display
  • 28 bottle capacity on classic wooden shelves
  • Designed for fully integrated installation

SPECIFICATIONS

Overview
Height of Cabinet 18.13" (46 cm)
Width 23.25" (59 cm)
Depth 22.13" (56 cm)
Depth with Handle 23.88" (61 cm)
Depth with door at 90° 44.75" (114 cm)
Bottles 28 bottles
Defrost Type Automatic
Door Glass
Cabinet Unfinished
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 71.0 lbs. (32 kg)
Shipping Weight 74.0 lbs. (34 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Wine Cellar
Number of Zones 1
Door Swing RHD
Reversible Yes
Shelf Type Wood
Shelf Qty 3
Thermostat Type Digital
Interior Light Yes
Fan Type Interior
Refrigerant Type R134a
Refrigerant Amount 1.27 oz.
High Side PSI 270.0
Low Side PSI 105.0
Interior Height 1 13.75" (35 cm)
Interior Width 1 18.88" (48 cm)
Interior Depth 1 14.88" (38 cm)
Temperature Range 42º to 72ºF
Sabbath Mode Yes

AVAILABLE UPGRADES

Exterior
LHD - Left hand door swing
Door reversal to left hand swing


California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

WHERE TO BUY

Invalid Format

DESCRIPTION

SUMMIT introduces fully integrated wine cellars for optimum storage and professional elegance.The VC28S is designed to store up to 28 bottles under the ideal conditions. The double pane tempered glass door ensures your collection is safely protected from UV light while offering a luxurious look with a seamless stainless steel frame. A professional handle adds a modern touch. The door swing is user reversible, offering more flexibility when positioning the unit.

Inside, the VC28S includes a digital thermostat for easy temperature management. Three wooden shelves hold bottles in classic style, with a floor specially slotted to store additional wine. The recessed LED lighting provides an elegant view of the interior, with an optional setting of display or functional mode. Additional features include an open door alarm, high/low temperature alarm and optional Sabbath Mode setting. The VC28S is auto defrost, with fan-forced cooling that ensures the interior temperature is evenly distributed and a condensation collection system that helps to maintain the correct level of humidity inside.

With a stunning look and quality design, the VC28S adds a great touch to any room. For our fully integrated dual zone wine cellar, see the VC60D. This unit is designed for fully integrated installation (cutout dimensions: 16 7/8" H x 21 1/2" W x 22 1/8" D; see user manual for additional information about providing proper ventilation and spacing for this unit).

FEATURES

Digital thermostat
Electronic controls ensure easy and intuitive temperature management, with a readout in Celsius or Fahrenheit (temperature range: 40ºF to 72ºF)
Dynamic compressor cooling
Ensures evenly cooled interior for proper storage
Reversible glass door
User-reversible door swing in double pane tempered glass for best protection from UV light
Slide-out wooden shelves
Store bottles safely in classic style
Open door alarm
Sounds after door is left open for over a minute to best prevent accidents
Interior light
Can be set for showcase mode, remaining on until manually turned off, or functional model (turning on when the door is opened and off when it is closed)
Temperature alarm
Alarm sounds off when unit's interior rises or falls out of the set range
Sabbath Mode
Optional setting lets you disable the lighting and alarm for 96 hours
Built-in installation
Designed for fully integrated installation (cutout dimensions: 16 7/8" H x 21 1/2" W x 22 1/8" D; see user manual for additional information about providing proper ventilation and spacing for this uni)
Humidity improvement
Proper humidity levels are maintained inside due to a specially designed condensation collection system
100% CFC free
Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 18.13" (46 cm)
Width 23.25" (59 cm)
Depth 22.13" (56 cm)
Depth with Handle 23.88" (61 cm)
Depth with door at 90° 44.75" (114 cm)
Bottles 28 bottles
Defrost Type Automatic
Door Glass
Cabinet Unfinished
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 71.0 lbs. (32 kg)
Shipping Weight 74.0 lbs. (34 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Wine Cellar
Number of Zones 1
Door Swing RHD
Reversible Yes
Shelf Type Wood
Shelf Qty 3
Thermostat Type Digital
Interior Light Yes
Fan Type Interior
Refrigerant Type R134a
Refrigerant Amount 1.27 oz.
High Side PSI 270.0
Low Side PSI 105.0
Interior Height 1 13.75" (35 cm)
Interior Width 1 18.88" (48 cm)
Interior Depth 1 14.88" (38 cm)
Temperature Range 42º to 72ºF
Sabbath Mode Yes

AVAILABLE UPGRADES

Exterior
LHD - Left hand door swing
Door reversal to left hand swing

DOWNLOADS

Download
BROCHURE w/ DRAWINGS
VC28S.pdf
Download
TECHNICAL DRAWING (.dwg)
VC28SWINECELLARA-C2000.dwg


California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice
