18" 8 lb. Drain-Free Icemaker, ADA Compliant

SKU: BIM18IFADA Matching refrigerator

No drain required for more flexibility in placing the icemaker

31.38" H x 17.75" W x 24.0" D

(80cm H x 45cm W x 61cm D)

OVERVIEW

  • 32" height for installation under lower ADA compliant counters
  • Produces and stores up to 8 lbs. of crescent ice cubes in a removable bin
  • Panel-ready door frame allows you to create a truly custom look under the counter
  • Uniquely sized just under 18 inches wide
  • No drain required for operation
  • Flexible design allows built-in or freestanding use
  • Fully frost-free for low maintenance operation

SPECIFICATIONS

Overview
Height of Cabinet 31.38" (80 cm)
Width 17.75" (45 cm)
Depth 24.0" (61 cm)
Depth with Handle 25.75" (65 cm)
Depth with door at 90° 40.0" (102 cm)
Capacity 2.7 cu.ft. (76 L)
Defrost Type Frost-Free
Door Panel-Ready
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.1
Voltage/Frequency 115 V AC/60 Hz
Weight 82.0 lbs. (37 kg)
Shipping Weight 85.0 lbs. (39 kg)
Estimated Time to Ship 5 to 7 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Icemaker
Door Swing RHD
Reversible Factory Reversible
Daily Ice Production 8.0 lbs. (4 kg)
Ice Storage Capacity 8.0 lbs. (4 kg)
Ice Shape Crescent
Number of Ice Cube Sizes 1
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R134a
Refrigerant Amount 3.9 oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Height 23.5" (60 cm)
Interior Width 12.75" (32 cm)
Interior Depth 16.75" (43 cm)
Compressor Step Height 4.5" (11 cm)
Compressor Step Width 12.75" (32 cm)
Compressor Step Depth 4.5" (11 cm)
Level Legs 4
Temperature Range -22 to 14ºF

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Extra key
Extra keys available for purchase
SSK
Stainless steel kickplate factory installed
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

WHERE TO BUY

Invalid Format

DESCRIPTION

Summit brings convenient luxury under the counter with built-in icemakers uniquely sized for use in ADA compliant settings.

Sized just under 18 inches wide and 32 inches high, the BIM18IFADA is ideal for use under lower counters following ADA compliant guidelines. The door comes with Summit's integrated stainless steel frame designed to accept overlay panels for a custom look that matches or complements other cabinetry. No drain or pump is required for use, offering more flexibility in where you place the unit.

Inside, the BIM18IFADA can produce and hold 8 lbs. of crescent-shaped ice cubes in the removable bucket. Additional chrome shelves allow you to store other frozen items as needed. This unit utilizes frost-free operation to help reduce user maintenance.

With its ideal size and customizable design, the BIM18IFADA is a great solution to keeping a steady supply of ice on hand in smaller ADA compliant kitchen spaces. Matching 18 inch wide refrigerators, beverage centers, and wine cellars are also available. Browse our website to explore our complete selection.

FEATURES

Integrated door frame
Stainless steel door frame accepts full overlay panels for users to create a seamless custom look (panel size: 17 1/2" W x 27 3/4" H; maximum weight: 10 lbs.)
ADA compliant
Sized just under 32" high for installation under lower ADA compliant counters
Built-in capable
Make the best use of space by installing your appliance under the counter
No pump or drain required
Convenient design allows more flexibility in positioning the unit
Ice production
Makes and stores up to 8 lbs. of crescent cubes
Removable bin
Bucket can be removed for fast and easy cleaning
Digital thermostat
Electronic controls for precise temperature management.
Digital display
Temperature readout can be shown in Celsius or Fahrenheit
Frost-free operation
Eliminates the need to manually defrost the interior
Extra shelves
Adjustable chrome shelves included to accommodate additional items
Flush back
Space saving design with easier cleanability
Fully finished black cabinet
Allows the unit to be used freestanding
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 31.38" (80 cm)
Width 17.75" (45 cm)
Depth 24.0" (61 cm)
Depth with Handle 25.75" (65 cm)
Depth with door at 90° 40.0" (102 cm)
Capacity 2.7 cu.ft. (76 L)
Defrost Type Frost-Free
Door Panel-Ready
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.1
Voltage/Frequency 115 V AC/60 Hz
Weight 82.0 lbs. (37 kg)
Shipping Weight 85.0 lbs. (39 kg)
Estimated Time to Ship 5 to 7 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Icemaker
Door Swing RHD
Reversible Factory Reversible
Daily Ice Production 8.0 lbs. (4 kg)
Ice Storage Capacity 8.0 lbs. (4 kg)
Ice Shape Crescent
Number of Ice Cube Sizes 1
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R134a
Refrigerant Amount 3.9 oz.
High Side PSI 270.0
Low Side PSI 103.0
Interior Height 23.5" (60 cm)
Interior Width 12.75" (32 cm)
Interior Depth 16.75" (43 cm)
Compressor Step Height 4.5" (11 cm)
Compressor Step Width 12.75" (32 cm)
Compressor Step Depth 4.5" (11 cm)
Level Legs 4
Temperature Range -22 to 14ºF

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Extra key
Extra keys available for purchase
SSK
Stainless steel kickplate factory installed
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
