20" Wide Electric Coil Range

SKU: TEM110CW

Delivery
This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.

Made in the USA

40.0" H x 20.0" W x 24.0" D

(102cm H x 51cm W x 61cm D)

OVERVIEW

  • 20" wide electric range made in the USA
  • Designed to meet ADA guidelines for improved accessibilty
  • Lower storage area for added convenience
  • Recessed oven door for cabinet protection
  • Includes an oven window and light for easier cooking
  • Made in the U.S.A.

SPECIFICATIONS

Overview
Height of Cabinet 40.0" (102 cm)
Width 20.0" (51 cm)
Depth 24.0" (61 cm)
Door Black
Cabinet Black
US Electrical Safety CSA
Voltage/Frequency 220 V AC/60 Hz
Weight 140.0 lbs. (64 kg)
Shipping Weight 145.0 lbs. (66 kg)
Estimated Time to Ship Next day shipping
Parts & Labor Warranty 1 Year
Electric Range
Oven Capacity 2.46 cu.ft. (70 L)
Cooktop Surface Porcelain
Element Type Coils
Number of Elements 4
Element #1 Size 6.0" (15 cm)
Element #1 Wattage 675.0
Element #2 Size 6.0" (15 cm)
Element #2 Wattage 675.0
Element #3 Size 6.0" (15 cm)
Element #3 Wattage 675.0
Element #4 Size 8.0" (20 cm)
Element #4 Wattage 975.0
Burner Controls Dial
Oven Controls Dial
Oven Light Yes
Backguard Yes
Cleaning Type Manual
Oven Rack Qty 2
Oven Window Yes
Oven Interior Height 14.0" (36 cm)
Oven Interior Width 16.0" (41 cm)
Oven Interior Depth 19.0" (48 cm)
Storage Compartment Yes
Broiler Location Inside Oven
Oven Door Black

AVAILABLE UPGRADES

Interior
Canadian Range Conversion
Range is modified at factory to meet CSA-C standards
Heat Sense
Temperature sensor cycles coil element to prevent cookware from exceeding flashpoint temperatures
Exterior
RangeCord4P - Installed 4-pronged cord
4-pronged NEMA 14-50P cord installed on stove
RangeCord3P - Installed 3-pronged cord
3-pronged NEMA 10-50P cord installed on stove
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

WHERE TO BUY

Invalid Format

DESCRIPTION

SUMMIT offers a wide selection of household ranges with high quality construction at superior value.

At just 20" wide, the TEM110CW brings quality cooking to apartments and other small kitchens. All controls are front-located to meet ADA guidelines for accessible use. The oven includes a window on the door and an interior light to make it easy to monitor your cooking. This unit includes a lower storage compartment ideal for keeping pots and pans out of the way. An anti-tip bracket is included for added safety. The interior includes two oven racks.

Made in the U.S.A., the TEM110CW is constructed from porcelain and steel for maximum durability. This unit comes in a jet black exterior finish.

FEATURES

20" wide
Perfectly sized for apartments and other homes with smaller kitchen spaces
Four coil elements
Surface features one 2100W 8" element and three 1200W 6" elements
Chrome drip pans
Each element includes a removable chrome pan for easier cleaning
Oven window with light
Easier monitoring of your cooking with an oven window and on/off light
Lower storage compartment
Keep pots and pans inside the lower compartment for easy storage
Waist-high broiler
Broiler is located inside the oven, making it easier to use
Recessed oven door
Smart design limits the depth and protects adjacent cabinets
Porcelain construction
Solid porcelain range top and oven
Removable oven door and range top
Black porcelain oven door and top can be removed for easier cleaning
Large oven capacity
Generous 2.46 cu.ft. oven interior is one of the largest sizes offered for 20" wide ranges
Oven racks
Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
Push-to-turn burner knobs
Burner knobs require a small amount of force to turn on for added protection against accidents; oven knob is not push-to-turn
Indicator lights
Control panel includes an 'on' light for the oven and burners for added safety when using the range
Broiler tray included
Porcelain broiler tray with grease well
Anti-tip bracket
Install to prevent accidents from tipping oven over
220V electric range
Cord not included
ADA compliant
Upfront controls and easy-to-operate knobs offer easier accessibility

SPECIFICATIONS

Overview
Height of Cabinet 40.0" (102 cm)
Width 20.0" (51 cm)
Depth 24.0" (61 cm)
Door Black
Cabinet Black
US Electrical Safety CSA
Voltage/Frequency 220 V AC/60 Hz
Weight 140.0 lbs. (64 kg)
Shipping Weight 145.0 lbs. (66 kg)
Estimated Time to Ship Next day shipping
Parts & Labor Warranty 1 Year
Electric Range
Oven Capacity 2.46 cu.ft. (70 L)
Cooktop Surface Porcelain
Element Type Coils
Number of Elements 4
Element #1 Size 6.0" (15 cm)
Element #1 Wattage 675.0
Element #2 Size 6.0" (15 cm)
Element #2 Wattage 675.0
Element #3 Size 6.0" (15 cm)
Element #3 Wattage 675.0
Element #4 Size 8.0" (20 cm)
Element #4 Wattage 975.0
Burner Controls Dial
Oven Controls Dial
Oven Light Yes
Backguard Yes
Cleaning Type Manual
Oven Rack Qty 2
Oven Window Yes
Oven Interior Height 14.0" (36 cm)
Oven Interior Width 16.0" (41 cm)
Oven Interior Depth 19.0" (48 cm)
Storage Compartment Yes
Broiler Location Inside Oven
Oven Door Black

AVAILABLE UPGRADES

Interior
Canadian Range Conversion
Range is modified at factory to meet CSA-C standards
Heat Sense
Temperature sensor cycles coil element to prevent cookware from exceeding flashpoint temperatures
Exterior
RangeCord4P - Installed 4-pronged cord
4-pronged NEMA 14-50P cord installed on stove
RangeCord3P - Installed 3-pronged cord
3-pronged NEMA 10-50P cord installed on stove
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
