24" Wide Single Zone Built-In Commercial Wine Cellar

SKU: SCR610BLCHPNR
Stainless steel shelves designed to store champagne and sparkling wine bottles at a slight angle for the perfect display in commercial settings
Estimated Time to Ship:

5 to 7 days

Color: Panel-Ready

*Additional features may vary

Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.
This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.
34.0" H x 23.63" W x 23.5" D
(86cm H x 60cm W x 60cm D)

Overview
Height of Cabinet 34.0" (86 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Depth with door at 90° 45.5" (116 cm)
Capacity 5.0 cu.ft. (142 L)
Bottles 20 bottles
Defrost Type Automatic
Door Glass/Panel-Ready Frame
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 0.8
Voltage/Frequency 115 V AC/60 Hz
Weight 140.0 lbs. (64 kg)
Shipping Weight 146.5 lbs. (66 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101065502
Wine Cellar
Number of Zones 1
Door Swing RHD
Reversible Factory Reversible
Shelf Type Steel
Shelf Qty 3
Thermostat Type Digital
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 0.99 oz.
High Side PSI 270.0
Low Side PSI 105.0
Interior Height 1 25.0" (64 cm)
Interior Width 1 19.38" (49 cm)
Interior Depth 1 17.38" (44 cm)
Compressor Step Height 3.75" (10 cm)
Compressor Step Width 19.38" (49 cm)
Compressor Step Depth 4.63" (12 cm)
Temperature Range 36 to 43ºF
Sound Level 37.4 dB

Door
T4 Door Tint
Neutral door tint in light smoke finish for moderate energy savings
T3 Door Tint
Reflective door tint in light blue finish for medium energy savings
T2 Door Tint
Tinted door in reflective deep blue finish with high energy savings
T1S Door Tint
Reflective door tint in dark smoke finish for maximum energy savings
T1 Door Tint
Tinted door in low-E mirror finish for maximum energy savings
Exterior
LHD - Left hand door swing
Door reversal to left hand swing
SSK - Stainless steel kickplate
Stainless steel kickplate factory installed

Commercially approved

ETL-S listed to NSF-7 Standards for use in commercial establishments

Built-in capable

Make the best use of space by installing this unit under the counter and flush with other cabinetry

Champagne racks

Stainless steel shelves are specially sized to store wider wine and champagne bottles

Panel-ready door trim

Door frame can be customized with a custom overlay panel (panel frame dimensions: 29 7/8" H x 23 1/8" W at 3/4" minimum thickness)

Bottle display

Cantilevered clips are pre-installed so that the shelving can be installed at a slight angle to provide a display of the bottle labels. Clips can be adjusted to a flat position to accommodate more shelves

Interior LED lighting

Fully lit interior with a striking blue LED hue, providing an attractive and energy efficient view

Double pane tempered glass door

Stainless steel trimmed glass door offers a full display of stored items

Stainless steel interior

Walls are constructed from stainless steel for added strength and easy cleanup

Factory installed lock

Keyed lock for a secure interior

Digital thermostat

Intuitive digital controls ensure easy temperature management

Factory reversible door

Door ships with a right hand door swing. For a left hand version, add option "LHD"

Automatic defrost

Reduced user maintenance with automatic defrost

Fan-forced cooling

Internal fan ensures the interior is evenly cooled from top to bottom

Sealed back

Space saving design with easier cleanability

Fully finished black cabinet

Allows the unit to be used freestanding

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Summit Commercial offers a unique selection of wine cellars designed for optimum storage and bottle presentation.

The SCR610BLCHPNR is an undercounter  wine cellar built to meet NSF-7 commercial standards. The slim 24 inch footprint takes up minimum floor space, with large 5 cu.ft. interior. This unit features a front-breathing design for built-in installation, with a fully finished black cabinet that also allows freestanding use. The double tempered glass door door features a panel-ready door trim that lets you customize the look to best match adjacent cabinetry (panel dimensions: 29 7/8" H x 23 1/8" W at 3/4" minimum thickness). A factory-installed lock offers additional security. This unit ships with a right hand door swing, but can be ordered to open from the other side by adding option LHD. Users provide their own handle.

Inside, the SCR610BLCHPNR includes stainless steel shelving specially designed to hold champagne and sparkling wine bottles at a slight angle, providing a full display of the label. The interior walls and floor are constructed from stainless steel for lasting durability in busy commercial settings. This unit is illuminated through the rear walls with efficient LED lighting in a striking blue hue. Digital controls make it easy to manage the interior.

With its unique design and commercial grade construction, the SCR610BLCHPNR is the perfect undercounter option for storing and displaying larger bottles.  Additional choices are available for outdoor use, and in larger sizes for higher bottle capacity. Browse our website for more options.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
