SBC635MWKD

Designed to store and dispense white wine at the proper serving temperature

33.5" H x 23.63" W x 25.0" D

(85cm H x 60cm W x 64cm D)

OVERVIEW

  • Complete wine tap kit includes tank for nitrogen/CO2 mix, regulator, and all the hardware needed to pour the perfect glass
  • Digital thermostat ensures easy and intuitive temperature management
  • Automatic defrost ensures minimum user maintenance
  • Ships with sturdy casters to install for optional portability

SPECIFICATIONS

Overview
Height of Cabinet 33.5" (85 cm)
Width 23.63" (60 cm)
Width with Door Open 25.0" (64 cm)
Depth 25.0" (64 cm)
Depth with door at 90° 47.0" (119 cm)
Capacity 5.6 cu.ft. (159 L)
Defrost Type Automatic
Door Black
Cabinet Black
US Electrical Safety UL
Canadian Electrical Safety ULC
Amps 0.86
Voltage/Frequency 115 V AC/60 Hz
Weight 80.0 lbs. (36 kg)
Shipping Weight 83.0 lbs. (38 kg)
Estimated Time to Ship 3 to 5 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Beer Dispenser
Door Swing RHD
Reversible Yes
Tap Kit Yes
Height with Tap 49.0" (124 cm)
Number of Taps 1
Thermostat Type Digital
Refrigerant R600a
Refrigerant Amount 1.13 oz.
High Side PSI 250.0
Low Side PSI 110.0
Inter Height 28.0" (71 cm)
Interior Width 20.5" (52 cm)
Interior Depth 19.0" (48 cm)
Compressor Step Height 8.25" (21 cm)
Wheel Qty 4
Temperature Range 33º to 50º F

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

WHERE TO BUY

Invalid Format

DESCRIPTION

Tap into the growing industry of draft wine with Summit's SBC635MWKD, a versatile wine keg dispenser designed to store wine kegs under the proper conditions.

Sized at just under 24" wide, the SBC635MWKD features a jet black finish with a user-reversible door swing. The exterior digital thermostat allows you to store white wine or rosé between 33º and 50ºF. The single tap system can serve one 1/6 wine keg or disposable keg, but the interior offers added room to store an additional 1/6 sized barrel. Automatic defrost operation ensures minimum user maintenance.

The SBC635MWKD  ships with a complete kit for serving wine on tap, including a draft tower, faucet, and keg coupler probe in complete 304 grade stainless steel. We include an empty canister best suited for a 75% nitrogen/25% CO2 mixture for optimum wine service. Additional features include a removable guard rail and drip tray for easier cleaning, as well as a caster set to allow optional mobility. This unit is designed for freestanding use.

FEATURES

Large interior
5.6 cu.ft. interior allows you to store an extra 1/6 size wine keg inside
Tap Kit
Ships with a complete wine tap kit that includes a dispenser tower, regulator, and all the connection equipment you need to serve from a 1/6 wine keg or disposable wine keg
Automatic defrost
Reduced user maintenance with auto defrost operation
Digital thermostat
Electronic controls ensure easy temperature management, with an external readout in Celsius or Fahrenheit
White wine/rosé temperature
Operates between 33º and 50ºF to keep a variety of white and blush wine chilled
Nitrogen/CO2 tank included
Canister is best suited for a 75% nitrogen/25% CO2 mixture
Reversible door
User-reversible door swing for added flexibility
Casters included (ships unassembled)
To make the dispenser portable, install this set of 2 1/2" high locking casters
Top guard rail (ships unassembled)
Attractive chrome guard rail helps to reduce spills and neaten service
Stainless steel floor cover
Interior includes steel cover to protect the floor when loading kegs
Cleaning kit included
Kit includes everything you need to keep your wine kegerator clean
Drip tray
Removable drip tray catches spills to help contain the mess
Fully finished black cabinet
Allows the unit to be used freestanding
100% CFC free
Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 33.5" (85 cm)
Width 23.63" (60 cm)
Width with Door Open 25.0" (64 cm)
Depth 25.0" (64 cm)
Depth with door at 90° 47.0" (119 cm)
Capacity 5.6 cu.ft. (159 L)
Defrost Type Automatic
Door Black
Cabinet Black
US Electrical Safety UL
Canadian Electrical Safety ULC
Amps 0.86
Voltage/Frequency 115 V AC/60 Hz
Weight 80.0 lbs. (36 kg)
Shipping Weight 83.0 lbs. (38 kg)
Estimated Time to Ship 3 to 5 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Beer Dispenser
Door Swing RHD
Reversible Yes
Tap Kit Yes
Height with Tap 49.0" (124 cm)
Number of Taps 1
Thermostat Type Digital
Refrigerant R600a
Refrigerant Amount 1.13 oz.
High Side PSI 250.0
Low Side PSI 110.0
Inter Height 28.0" (71 cm)
Interior Width 20.5" (52 cm)
Interior Depth 19.0" (48 cm)
Compressor Step Height 8.25" (21 cm)
Wheel Qty 4
Temperature Range 33º to 50º F

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing

DOWNLOADS

Download
BROCHURE
SBC635MWKD.pdf
Download
MSDS INFORMATION
MSDS_R600a_C.pdf
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
