30" Wide Gas Range
(112cm H x 76cm W x 61cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 44.0" (112 cm) |
| Width | 30.0" (76 cm) |
| Depth | 24.0" (61 cm) |
| Door | White |
| Cabinet | White |
| Weight | 170.0 lbs. (77 kg) |
| Shipping Weight | 177.0 lbs. (80 kg) |
| Parts & Labor Warranty | 1 Year |
| UPC | 761101060965 |
|
Gas Range
|
|
| Ignition | Spark |
| LP Convertible | With Kit LP S2 Accessory |
| Oven Capacity | 3.7 cu.ft |
| Cooktop Surface | Porcelain |
| Burner Type | Sealed |
| Number of Burners | 4 |
| Burner #1 BTU | 120000.0 |
| Burner #2 BTU | 9100.0 |
| Burner #3 BTU | 9100.0 |
| Burner #4 BTU | 5000.0 |
| Burner Controls | Dial |
| Oven Controls | Dial |
| Oven Light | Yes |
| Cooking Timer | Yes |
| Backguard | Yes |
| Backguard Display | Yes |
| Cleaning Type | Manual |
| Oven Rack Qty | 2 |
| Oven Window | Yes |
| Oven Interior Height | 14.0" (36 cm) |
| Oven Interior Width | 24.0" (61 cm) |
| Oven Interior Depth | 19.0" (48 cm) |
| Broiler Location | Below Oven |
| Broiler Door | White |
AVAILABLE UPGRADES
| Exterior | |
|---|---|
|
FEATURES
Natural gas range; can be converted to LP Gas in our shop or ordered with KIT LP S2 for conversion
Easy cleanup on boil-overs and accidental spills
Right front burner features 12,000 BTU output for powerful cooking
Rear left burner reaches a maximum of 5000 BTUs, ideal for simmering sensitive items or keeping dishes warm without overheating
Easier monitoring of your cooking with an oven window and on/off light
Backguard includes time readout
Gas spark ignition for automatic lighting of burners
Lower compartment for separate broiling with even heat distribution
White porcelain removable oven top and door
Burners include a removable cap for easy cleaning
Two-piece porcelain broiler tray with grease well
To prevent accidents, knobs require a small amount of force when turning
Smart design limits the depth and protects adjacent cabinets
Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
Upfront controls and easy-to-operate knobs offer easier accessibility
DESCRIPTION
SUMMIT offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens. The WTM2307KSW is an apartment-sized gas range sized at 30" wide, with a generous 3.7 cu.ft oven interior that still can accommodate large trays. The oven includes a window and interior light to make it easy to monitor your cooking and a digital clock and timer that helps you plan your cooking with ease. Four sealed gas burners offer safer and cleaner cooking. This new model includes a high output 12000 BTU burner for powerful heating conveniently located in the front right corner for easy access. This unit also includes a 5000 BTU burner in the rear, an ideal design for simmering at lower power or keeping food warm without overcooking. This unit has a drop-down compartment for broiling and utilizes an electronic ignition system for added safety. Recessed doors and a 24" depth also help to maximize kitchen space while protecting adjacent cabinetry. The WTM2307KSW comes in an all-white exterior finish with a high backguard that helps to protect your walls from splash-overs and grease stains. Fully constructed from steel and porcelain, Summit's American-made cooking line offers long-lasting quality for the home. Additional choices are available in 20" and 24" wide fits.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
