20" Wide Gas Range
(91cm H x 51cm W x 61cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 36.0" (91 cm) |
| Width | 20.0" (51 cm) |
| Depth | 24.0" (61 cm) |
| Door | Black |
| Cabinet | Black |
| US Electrical Safety | CSA |
| Weight | 140.0 lbs. (64 kg) |
| Shipping Weight | 145.0 lbs. (66 kg) |
| Parts & Labor Warranty | 1 Year |
| UPC | 761101058122 |
|
Gas Range
|
|
| Ignition | Spark |
| LP Convertible | With Kit LP S2 Accessory |
| Oven Capacity | 2.46 cu.ft |
| Cooktop Surface | Porcelain |
| Burner Type | Sealed |
| Number of Burners | 4 |
| Burner #1 BTU | 9100.0 |
| Burner #2 BTU | 9100.0 |
| Burner #3 BTU | 9100.0 |
| Burner #4 BTU | 9100.0 |
| Burner Controls | Dial |
| Oven Controls | Dial |
| Cleaning Type | Manual |
| Oven Rack Qty | 2 |
| Oven Interior Height | 14.0" (36 cm) |
| Oven Interior Width | 16.0" (41 cm) |
| Oven Interior Depth | 19.0" (48 cm) |
| Broiler Location | Below Oven |
AVAILABLE UPGRADES
| Exterior | |
|---|---|
|
|
| Interior | |
|
FEATURES
Upfront controls and easy-to-operate knobs offer easier accessibility
Apartment sized to fit in small or galley kitchens
Low backguard can blend into other cabinetry and lets you choose your own wall design behind the range
Easy cleanup on boil-overs and accidental spills
Gas spark ignition for automatic lighting of burners
Black porcelain removable oven top and door
Low rear trim is finished in stainless steel for an attractive look
Lower compartment for separate broiling with even heat distribution
Two-piece porcelain broiler tray with grease well
Smart design limits the depth and protects adjacent cabinets
To prevent accidents, knobs require a small amount of force when turning
Burners include a removable cap for easy cleaning
Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
For LP conversion, contact our office at 718-893-3900 ext. 220
DESCRIPTION
SUMMIT offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens. The TTM1107CRS is an apartment-sized gas range sized at just 20" wide, with a generous 2.46 cu.ft oven interior that still can accommodate large trays. The broiler is located below the oven in a drop-down compartment. Four sealed 9100 BTU gas burners offer safer cleaning and cleaner cooking. This unit utilizes an electronic ignition system for added safety. The TTM1107CSRT comes in a jet black finish. The low stainless steel backguard creates a modern slide-in look that is easier to integrate into your own kitchen design. Fully constructed from steel and porcelain, Summit's American-made cooking line offers long-lasting quality for the home. Additional choices are available in 24" and 30" wide fits.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
