20" Wide Gas Range, Open Burners

SKU: TNM1107C
Made in the USA
Estimated Time to Ship:

Next day shipping; multi-piece orders may extend lead time. Call 718-893-3900 ext. 507 to discuss

40.0" H x 20.0" W x 24.0" D
(102cm H x 51cm W x 61cm D)

Overview
Height of Cabinet 40.0" (102 cm)
Width 20.0" (51 cm)
Depth 24.0" (61 cm)
Door Black
Cabinet Black
US Electrical Safety CSA
Voltage/Frequency 115 V AC/60 Hz
Weight 140.0 lbs. (64 kg)
Shipping Weight 145.0 lbs. (66 kg)
Parts & Labor Warranty 1 Year
UPC 761101054070
Gas Range
Ignition Spark
LP Convertible With Kit LP Accessory
Oven Capacity 2.46 cu.ft
Cooktop Surface Porcelain
Burner Type Open
Number of Burners 4
Burner #1 BTU 9000.0
Burner #2 BTU 9000.0
Burner #3 BTU 9000.0
Burner #4 BTU 9000.0
Burner Controls Dial
Oven Controls Dial
Backguard Yes
Cleaning Type Manual
Oven Rack Qty 2
Oven Interior Height 14.0" (36 cm)
Oven Interior Width 16.0" (41 cm)
Oven Interior Depth 19.0" (48 cm)
Broiler Location Below Oven
Broiler Door Black
Oven Door Black

Interior
Canadian Range Conversion
Range is modified at factory to meet CSA-C standards
Exterior
LP Conversion
Have this range factory converted to LP gas. KIT LP is included

Made in the USA

Designed and constructed domestically

Slim 20 inch width

Apartment-sized width offers all the functionality you need in a smaller footprint

24 inch depth

Shallower fit is ideal for L-shaped and galley kitchens

Four open burners

9000 BTU burners with built-in enamel grates to meet most cooking needs

Designed for natural gas

Set for use with natural gas connection. To convert for propane use, add Kit LP

Electronic ignition

Spark ignition system with a pre-installed 115V 3-prong cord

Drop-down broiler compartment

Lower compartment for separate broiling with even heat distribution

Recessed oven door

Smart design limits the depth and protects adjacent cabinets

Upfront controls

Push-to-turn knobs offer easier, safer access, preventing users from reaching over hot burners to adjust

Adjustable oven racks

Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes

ADA compliant design

Upfront controls and easy-to-operate knobs offer easier accessibility

Porcelain and steel construction

Lasting durability with solid construction inside and out designed to hold up to everyday kitchen use

Removable oven door and range top

Porcelain oven door and top can be removed for easier cleaning

Anti-tip bracket included

Included for user installation to help prevent tipping

Broiler pan included

Two-piece porcelain broiler tray with grease well

Black exterior finish

Jet black finish brings a modern look to smaller kitchen spaces

Summit Appliance offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens.

The TNM1107C is an apartment-sized gas range sized at just 20" wide, with a generous 2.46 cu.ft oven interior that can accommodate large trays. Two adjustable oven racks are included. The broiler is located below the oven in a drop-down compartment. Four open 9000 BTU gas burners accommodate most of your stovetop heating needs, with upfront push-to-turn knobs that let you adjust your cooking without reaching over hot burners. This unit utilizes an electronic ignition system for added safety.

The TNM1107C comes in a jet black finish to suit any kitchen setting. This unit has a recessed oven door and is conveniently sized at just 24" deep for a better fit in galley in L-shaped kitchens, where every inch counts. Constructed from porcelain and steel, the TNM1107C offers lasting durability. We include an anti-tip bracket for added safety.

With its classic style and quality construction, Summit's made in the USA cooking line offers reliable cooking for smaller homes. Additional choices are available in 24", 30", and 36" wide fits. This unit ships ready for natural gas connections. To use with propane, add the Kit LP.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
