30" Wide Built-In Wine/Beverage Center

SKU: SWBV3071

Tints
Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.

Dual zone design allows you to store craft beer and wine in elegant style

34.0" H x 29.5" W x 23.5" D

(86cm H x 75cm W x 60cm D)

OVERVIEW

  • Unique dual zone design lets you store wine and craft beer under different temperatures
  • Flexible design allows built-in or freestanding use in 30" wide spaces
  • Stainless steel trimmed glass doors feature modern French door swing
  • Digital controls offer easy and intuitive temperature management
  • Fully featured with Sabbath mode and audible alarms for high temperature and open door alerts

SPECIFICATIONS

Overview
Height of Cabinet 34.0" (86 cm)
Width 29.5" (75 cm)
Depth 23.5" (60 cm)
Depth with Handle 25.25" (64 cm)
Depth with door at 90° 37.0" (94 cm)
Capacity 5.8 cu.ft. (164 L)
Defrost Type Automatic
Door Glass
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.5
Voltage/Frequency 115 V AC/60 Hz
Weight 132.0 lbs. (60 kg)
Shipping Weight 137.0 lbs. (62 kg)
Estimated Time to Ship Out of stock; ETA 9/22/2019
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Wine Cellar
Number of Zones 2
Door Swing French
Adjustable Shelves Yes
Shelf Type Wire and Wood
Shelf Qty 9
Thermostat Type Digital
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 1.23 oz.
High Side PSI 270.0
Low Side PSI 105.0
Interior Height 1 26.38" (67 cm)
Interior Width 1 12.0" (30 cm)
Interior Depth 1 17.5" (44 cm)
Compressor Step Height 3.0" (8 cm)
Compressor Step Width 26.75" (68 cm)
Compressor Step Depth 5.0" (13 cm)
Level Legs 2
Temperature Range Left side: 36º to 43ºF; Right side: 41º to 72ºF
Interior Height 2 24.75" (63 cm)
Interior Width 2 12.0" (30 cm)
Interior Depth 2 17.5" (44 cm)
Sabbath Mode Yes

AVAILABLE UPGRADES

Door
T1SF Door Tint
Reflective door tint in dark smoke finish for maximum energy savings on full-size and two-door models
T2F Door Tint
Tinted door in reflective deep blue finish with high energy savings
T3F Door Tint
Reflective door tint in light blue finish for medium energy savings
T4F Door Tint
Neutral door tint in light smoke finish for moderate energy savings
Exterior
Extra key
Extra keys available for purchase
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

WHERE TO BUY

Invalid Format

DESCRIPTION

SUMMIT's collection of built-in undercounter wine cellars offers quality storage with user-friendly convenience and elegant style.

The SWBV3071 is a 30" wide wine and craft beer cooler designed for built-in installation under counters. The fully finished black cabinet also allows freestanding use. This unit includes two stainless steel trimmed glass doors with a unique French door swing. Both include factory installed locks and professional handles. Front locks offer keyed security for both compartments. The sealed back design ensures easier cleanability.

Two separate zones feature independent digital thermostats, allowing you to store craft beer or white wine in the left side while preserving your red wine in the right. The left beverage compartment includes three slide-out black wire shelves with wooden trim to match the six wooden shelves included in the right. Both sections feature a slotted floor to hold additional bottles. The digital control panel features an LED temperature readout in Celsius or Fahrenheit. Recessed LED lighting in a white hue offers an attractive and efficient presentation.

With its attractive style and user-friendly features, the SWBV3071 is a great addition to any home looking to bring versatile beverage storage under the counter.

FEATURES

Built-in capable
Make the best use of space by installing this unit under the counter
Dual zone design
Two independent zones allow you to store both red and white wine or craft beer at the proper conditions
Digital controls
Interior digital thermostat lets you separately manage the temperature of each section, with a readout viewable in Celsius or Fahrenheit
Generous storage capacity
Store up to 33 standard Bordeaux style wine bottles in the right section and up to 72 8 oz. cans or 48 12 oz. bottles in the beverage section. To accommodate wider Burgundy style wine or champagne bottles, you can remove every other wine shelf
Recessed LED lighting
Gentle and energy efficient LED lighting in an attractive white hue offers an elegant view of stored items
Adjustable wooden shelves
Red wine section includes six removable wooden shelves for proper bottle storage
Adjustable beverage shelves
Craft beer section is equipped with three adjustable black wire shelves with an attractive wooden trim to complement the wine section
Slotted floors
Floor is specially designed with slots to allow you to store larger champagne or Burgundy style bottles safely on their sides
Professional handles
Sleek stainless steel handles add an elegant touch to any setting
Glass doors
French door swing offers a modern look, with stainless steel door trim for an added accent
Factory installed locks
Keyed locks on both zones offer separate security for interior contents
Automatic defrost
Reduced user maintenance with automatic defrost
Fan-forced cooling
Internal fans ensure both interiors have a consistent temperature from top to bottom
Sabbath mode
Setting allows you to disable the digital displays, lights, and alarms for religious observance.
High temperature alarm
Audible alarm sounds if the interior temperature rises above the recommended range
Open door alarm
Alarm will sound if either door is left open for over 60 seconds
Temperature memory function
In the event of power loss, the unit will retain its last temperature settings upon power recovery
Sealed back
Space-saving design with no exposed coils in the rear offers easy cleanability
Right angle plug
Design allows you to plug the unit in flush against the wall socket with no need to add extra depth
Fully finished cabinet
Allows the unit to be used freestanding
100% CFC free
Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 34.0" (86 cm)
Width 29.5" (75 cm)
Depth 23.5" (60 cm)
Depth with Handle 25.25" (64 cm)
Depth with door at 90° 37.0" (94 cm)
Capacity 5.8 cu.ft. (164 L)
Defrost Type Automatic
Door Glass
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.5
Voltage/Frequency 115 V AC/60 Hz
Weight 132.0 lbs. (60 kg)
Shipping Weight 137.0 lbs. (62 kg)
Estimated Time to Ship Out of stock; ETA 9/22/2019
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Wine Cellar
Number of Zones 2
Door Swing French
Adjustable Shelves Yes
Shelf Type Wire and Wood
Shelf Qty 9
Thermostat Type Digital
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 1.23 oz.
High Side PSI 270.0
Low Side PSI 105.0
Interior Height 1 26.38" (67 cm)
Interior Width 1 12.0" (30 cm)
Interior Depth 1 17.5" (44 cm)
Compressor Step Height 3.0" (8 cm)
Compressor Step Width 26.75" (68 cm)
Compressor Step Depth 5.0" (13 cm)
Level Legs 2
Temperature Range Left side: 36º to 43ºF; Right side: 41º to 72ºF
Interior Height 2 24.75" (63 cm)
Interior Width 2 12.0" (30 cm)
Interior Depth 2 17.5" (44 cm)
Sabbath Mode Yes

AVAILABLE UPGRADES

Door
T1SF Door Tint
Reflective door tint in dark smoke finish for maximum energy savings on full-size and two-door models
T2F Door Tint
Tinted door in reflective deep blue finish with high energy savings
T3F Door Tint
Reflective door tint in light blue finish for medium energy savings
T4F Door Tint
Neutral door tint in light smoke finish for moderate energy savings
Exterior
Extra key
Extra keys available for purchase

DOWNLOADS

Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
