Shallow Depth Indoor/Outdoor Beverage Cooler

SKU: SPR489OSCSSPNR

Panel-ready door trim lets you customize the unit to best match your setting

Estimated Time to Ship: 2 to 4 days

Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.

This unit can be used for commercial or residential applications. It meets applicable U.S. Department of Energy (DOE) standards for both household and commercial energy usage. For information on its commercial sanitation listing, see Specifications.

33.88" H x 19.0" W x 17.75" D

(86cm H x 48cm W x 45cm D)

SPECIFICATIONS

Overview
Height of Cabinet	33.88" (86 cm)
Width	19.0" (48 cm)
Depth	17.75" (45 cm)
Depth with door at 90°	34.75" (88 cm)
Capacity	3.13 cu.ft. (89 L)
Defrost Type	Automatic
Door	Glass/Panel-Ready Frame
Cabinet	Stainless Steel
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Energy Usage/Year	285.0kWh/year
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Weight	85.0 lbs. (39 kg)
Shipping Weight	90.0 lbs. (41 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Refrigerator Features
Door Swing	RHD
Reversible	Factory Reversible
Height Adjustable	Yes
Shelf Type	Glass
Shelf Qty	3
Adjustable Shelves	Yes
Can Storage	Yes
Thermostat Type	Dial
Fan Type	Interior
Refrigerant Type	R600a
Refrigerant Amount	0.88oz.
High Side PSI	320.0
Low Side PSI	120.0
Level Legs Qty	2
Interior Light	Yes
Temperature Range	34 to 50ºF
Sound Level	32.6 dB
Dimensions
Interior Height	29.0" (74 cm)
Interior Width	16.0" (41 cm)
Interior Depth	12.75" (32 cm)
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	16.0" (41 cm)
Compressor Step Depth	6.25" (16 cm)

AVAILABLE UPGRADES

Door

T1 Door Tint Tinted door in low-E mirror finish for maximum energy savings	T1S Door Tint Reflective door tint in dark smoke finish for maximum energy savings
T2 Door Tint Tinted door in reflective deep blue finish with high energy savings	T3 Door Tint Reflective door tint in light blue finish for medium energy savings
T4 Door Tint Neutral door tint in light smoke finish for moderate energy savings

Exterior

Latch for door

Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.

LHD - Left hand door swing

Door reversal to left hand swing

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

California residents:

WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

FEATURES

Shallow depth
Unique 17 3/4" depth is ideal for home wet bars, island kitchens, and other applications with limited footprint space

Built-in capable
Make the best use of space by installing your refrigerator under the counter

Panel-ready door trim
Door frame can be customized with a custom overlay panel (panel frame dimensions: 31 9/16" H x 18 3/4" W at 3/4" minimum thickness)

Weatherproof design
Approved for use in the outdoors, with a sealed exterior and double pane tempered glass door

Commercially approved
ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings

Stainless steel wrapped exterior
Cabinet features 304 grade stainless steel construction for added durability and a professional look

Double pane tempered glass door
Heat resistant design provides clear view of stored products

Automatic defrost
Reduced user maintenance with auto defrost system

Adjustable shelves
Three glass shelves with six positions for optimal storage and easy cleaning

LED lighting
Automatically illuminates when the door is open for an attractive and energy efficient view

White interior finish
White interior offers improved visibility of stored contents

Adjustable thermostat
Dial thermostat with seven temperature settings offers easy temperature management

Versatile construction
Meets both residential and commercial standards

Sealed back
Space saving design with easier cleanability and added protection from the elements

Right-angle plug
Provides flexibility in unit placement without needing added depth

Factory installed lock
Door includes a lock and key for optional security. If planning to use the lock, be sure to include a 5/8" hole in the lower center of your custom panel

Height adjustable
Four leveling legs allow you to adjust the height between 33 7/8" and 34 1/2" to best fit your undercounter space

Fully finished cabinet
Allows the unit to be used freestanding

100% CFC free
Environmentally friendly design does not contain ozone-damaging chemicals

DESCRIPTION

Summit's line of built-in undercounter outdoor appliances includes slim-fitting display beverage centers designed for optimum storage and product presentation.

The SPR489OSCSSPNR features a versatile design that meets NSF-7 and UL-471 commercial standards, but is also approved for residential use. Sized with a slim 19 inch width and 17 3/4 inch shallow depth, it features a stainless steel wrapped cabinet with a sealed back for safe installation in the outdoors. The height can be adjusted between 33 7/8 and 34 1/2 inches to best suit your space. The double pane tempered glass door includes a panel-ready trim that lets you create a custom look to match or complement other cabinetry (panel dimensions: 18 3/4 inch W x 31 9/16 inch H at a minimum of 3/4 inches thick). Customers supply their own handle to best match their setting. The space-saving right angle plug and integrated hinge offer added space savings, while the stainless steel kickplate completes the look.

Inside, the SPR489OSCSSPNR utilizes an internal fan to ensure the interior is evenly cooled from top to bottom. An automatic defrost system allows for minimal user maintenance, while the white interior and LED lighting allows full visibility of stored items. Three adjustable glass shelves with six positions provide optimal storage capacity inside the 3.1 cu. ft. interior. The dial thermostat, with seven temperature settings, is located in the upper-right corner for easy temperature management.

The SPR489OSCSSPNR can be installed indoors or outdoors and is designed for built-in or freestanding use. Additional panel-ready choices are available in 15 inch, 18 inch, and 24 inch wide fits. Browse our full selection to find the perfect fit.
