Shallow Depth Indoor/Outdoor Beverage Cooler, ADA Compliant

SKU: SPR488BOSADA
Weatherproof design for reliable beverage storage in outdoor commercial settings, with a uniquely shallow depth for a better fit
Estimated Time to Ship:

3 to 5 days

Interior Finish:
Cabinet:

*Additional features may vary

Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.
This unit can be used for commercial or residential applications. It meets applicable U.S. Department of Energy (DOE) standards for both household and commercial energy usage. For information on its commercial sanitation listing, see Specifications.
32.5" H x 19.0" W x 17.0" D
(83cm H x 48cm W x 43cm D)

Overview
Height of Cabinet 32.5" (83 cm)
Width 19.0" (48 cm)
Depth 17.0" (43 cm)
Depth with Handle 18.63" (47 cm)
Depth with door at 90° 34.75" (88 cm)
Capacity 3.13 cu.ft. (89 L)
Defrost Type Automatic
Door Glass
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Energy Usage/Year 285.0kWh/year
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 70.0 lbs. (32 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101077796
Refrigerator Features
Door Swing RHD
Reversible Yes
Shelf Type Glass
Shelf Qty 3
Adjustable Shelves Yes
Can Storage Yes
Thermostat Type Dial
Fan Type Interior
Refrigerant Type R600a
Refrigerant Amount 0.88oz.
High Side PSI 320.0
Low Side PSI 120.0
Level Legs Qty 2
Interior Light Yes
Temperature Range 34 to 50ºF
Sound Level 32.6 dB
Dimensions
Interior Height 29.0" (74 cm)
Interior Width 16.0" (41 cm)
Interior Depth 12.75" (32 cm)
Compressor Step Height 7.0" (18 cm)
Compressor Step Width 16.0" (41 cm)
Compressor Step Depth 6.25" (16 cm)

Exterior
LHD - Left hand door swing
Door reversal to left hand swing
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
Door
T1 Door Tint
Tinted door in low-E mirror finish for maximum energy savings
T1S Door Tint
Reflective door tint in dark smoke finish for maximum energy savings
T2 Door Tint
Tinted door in reflective deep blue finish with high energy savings
T3 Door Tint
Reflective door tint in light blue finish for medium energy savings
T4 Door Tint
Neutral door tint in light smoke finish for moderate energy savings

Built-in capable

Make the best use of space by installing your refrigerator under the counter

ADA compatible height

Sized at 32.5" high for installation under most lower ADA compliant counters

17" shallow depth

Ideal for home wet bars, island kitchens, and other applications with limited footprint space

Weatherproof design

Approved for use in the outdoors, with a sealed exterior and double pane tempered glass door

Commercially approved

ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings

Double pane tempered glass door

Heat resistant design provides clear view of stored products, with an elegant trim in seamless stainless steel

Automatic defrost

Reduced user maintenance with auto defrost system

Reversible door

User-reversible door swing makes it easy to adjust to your setting as needed

Factory installed lock

Keyed lock offers added security, with two keys included

Professional handle

Stainless steel handle adds an attractive touch

Adjustable shelves

Three glass shelves with six positions for optimal storage and easy cleaning

LED lighting

Automatically illuminates when the door is open for an attractive and energy efficient view

Black interior finish

Allows for easy cleaning and organization within the interior of the unit

Adjustable thermostat

Dial thermostat with seven temperature settings offers easy temperature management

Versatile construction

Versatile design allows for residential use

Sealed back

Space saving design with easier cleanability and added protection from the elements

Fully finished black cabinet

Allows the unit to be used freestanding

Right-angle plug

Provides flexibility in unit placement without needing added depth

100% CFC free

Environmentally friendly design does not contain ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Summit's line of outdoor appliances includes slim-fitting, ADA compliant display beverage centers designed for optimum storage and product presentation.

The SPR488BOSADA features a versatile design that meets NSF-7 and UL-471 commercial standards, but is also approved for residential use. Sized at just 19 inches wide and 17 inches deep, it features a jet black cabinet with a sealed back for safe installation in the outdoors. The user-reversible double pane tempered glass door includes a seamless stainless steel trim and a pro-style handle. A factory-installed lock offers added security, while the space-saving right-angle plug and integrated hinge provide added flexibility in unit placement. Two leveling legs keep the unit level on uneven surfaces.

Inside, the SPR488BOSADA utilizes an internal fan to ensure the interior is evenly cooled from top to bottom, while the automatic defrost system allows for minimal user maintenance. LED lighting allows full visibility of stored items in the jet black interior. Three adjustable glass shelves with six positions provide optimal storage capacity inside the 3.1 cu. ft. interior. The dial thermostat, with seven temperature settings, is located in the upper-right corner for easy temperature management.

The SPR488BOSADA is sized at 32.5 inches high to fit under most lower ADA compliant counters. This unit can be used built-in or freestanding in indoor or outdoor settings.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
