24" Wide 3-Drawer All-Refrigerator

SKU: SP6DBSSTB7

Assembled in the USA with full stainless steel construction inside and out

DISCONTINUED- REPLACED BY FF642D

This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

33.25" H x 23.75" W x 23.58" D
(84cm H x 60cm W x 60cm D)

Overview
Height of Cabinet	33.25" (84 cm)
Width	23.75" (60 cm)
Depth	23.58" (60 cm)
Depth with Handle	24.63" (63 cm)
Depth with door at 90°	40.5" (103 cm)
Capacity	3.1 cu.ft. (88 L)
Defrost Type	Automatic
Door	Stainless Steel
Cabinet	Stainless Steel
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.2
Weight	120.0 lbs. (54 kg)
Shipping Weight	115.5 lbs. (52 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101069548
Refrigerator Features
Height Adjustable	1
Thermostat Type	Dial
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.64oz.
High Side PSI	180.0
Low Side PSI	80.0
Level Legs Qty	4
Interior Drawers	Yes
Interior Drawers Qty	3
Drawer Dimensions
Interior Height 1	6.25" (16 cm)
Interior Width 1	18.63" (47 cm)
Interior Depth 1	11.5" (29 cm)
Interior Height 2	6.25" (16 cm)
Interior Width 2	18.63" (47 cm)
Interior Depth 2	16.0" (41 cm)
Interior Height 3	6.25" (16 cm)
Interior Width 3	17.25" (44 cm)
Interior Depth 3	16.0" (41 cm)
Dimensions
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	18.63" (47 cm)
Compressor Step Depth	6.0" (15 cm)

Exterior

HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix	SSK - Stainless steel kickplate Stainless steel kickplate factory installed
Latch - Factory-installed door latch requires manual release to open unit Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.	DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	Alarm/Thermometer - Factory-installed alarm with external temperature readout Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
Legs to raise unit height 6" high leveling legs	DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Interior

FC - Internal Fan

Commercially approved

ETL-S listed to NSF-7 Standards for use in commercial establishments

Built-in capable

Make the best use of space by installing your appliance under the counter and flush with other cabinets

Fully finished cabinet

Allows the refrigerator to be used freestanding

Stainless steel construction

Enhance any room with durable luxury

Slim undercounter dimensions

Less than 24 inches wide to fit tight spaces

Height adjustable

Four large leveling legs let you adjust unit height for the best undercounter fit

Three slide-out drawers

Easy gliding drawers offer more storage options

Automatic defrost

Reduced maintenance with auto defrost system

Professional towel bar handles

Curved stainless steel handles add function and elegance, providing more room for a comfortable grip

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

SUMMIT COMMERCIAL offers a quality line of commercially approved drawer refrigerators assembled in the U.S.A. and fully constructed from stainless steel.

The SP6DBSSTB7 is a 24" wide three-drawer all-refrigerator that can be used built-in or freestanding. Three sliding drawers feature curved towel bar handles and magnetic gaskets to ensure a tight seal when closed. The cabinet and drawers are constructed from durable stainless steel to ensure long-lasting luxury with a professional look.

Automatic defrost ensures minimum user maintenance, with a dial thermostat for easy temperature management. This model is ETL-S listed to NSF-7 standards for commercial use. For this unit in lower ADA compliant height, see the SP6DBSSTB7ADA.

BROCHURE w/ DRAWINGS
SP6DBSSTB7.pdf

TECHNICAL DRAWING (.dwg)
SP6DSSTBDRAWERREFRIGERATORA-C2000.dwg

USE & CARE
SP6DB_Series_Drawer_Refrigerators.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
