SGWO30SS

Designed and constructed in Italy, with luxury style in brushed stainless steel

27.0" H x 29.5" W x 22.63" D

(69cm H x 75cm W x 57cm D)

OVERVIEW

  • 30" wide gas wall oven brings full cooking convenience to unique wall cutouts
  • Made in Italy for Summit
  • Stainless steel front with pro style handle
  • Includes broil and convection function for versatile cooking
  • Can be used with natural or LP gas connections
  • Large oven window and interior light makes it easy to monitor your dishes

SPECIFICATIONS

Overview
Height of Cabinet 27.0" (69 cm)
Width 29.5" (75 cm)
Depth 22.63" (57 cm)
Depth with Handle 24.63" (63 cm)
Depth with door at 90° 39.75" (101 cm)
Capacity 3.0 cu.ft. (85 L)
Door Stainless Steel
Cabinet Stainless Steel
US Electrical Safety CSA
Amps 15.0
Voltage/Frequency 115 V AC/60 Hz
Weight 144.0 lbs. (65 kg)
Shipping Weight 149.0 lbs. (68 kg)
Parts & Labor Warranty 1 Year
Gas Walloven
Ignition Spark
LP Convertible Yes
Oven Capacity 3.0
Controls Dial
Oven Light Yes
Cooking Timer Yes
Cleaning Type Manual
Oven Rack Qty 3
Oven Window Yes
Interior Height 13.75" (35 cm)
Interior Width 23.0" (58 cm)
Interior Depth 16.0" (41 cm)
Cutout Height 26.63" (68 cm)
Cutout Width 28.0" (71 cm)
Cutout Depth 24.0" (61 cm)


California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

WHERE TO BUY

Invalid Format

DESCRIPTION

Made in Italy for Summit, the SGWO30SS is a 30" wide gas wall oven designed to bring true luxury to built-in cooking.

The SGWO30SS features stainless steel construction, with a pro style handle and color-matched knobs to complete the look. The large oven window and interior light make it easy to monitor your cooking. A digital clock and timer is included in the manifold.

Inside, three adjustable oven racks allow you to accommodate a range of sizes. The 12,000 BTU oven includes settings to bake and broil, with a convection fan that can be used with either function for even heating on your dishes. We include a porcelain broiler pan with a metal grate for added cooking convenience.

This unit comes set for natural gas but can be converted for LP connections (no kit required). It utilizes electronic ignition and includes a pre-installed power cord.

With its versatile functions and stunning design, the SGWO30SS takes built-in cooking to a new level of excellence.

FEATURES

Stainless steel construction
Professional style built to last with brushed stainless steel construction on the door and manifold
Professional handle
Solid tube handle in brushed stainless steel for a luxury look and strong grip
Oven window and light
Keep track of your cooking with the convenient window with interior oven light
Digital clock and timer
Added convenience for easier cooking
Broil function
Broiler is located inside main cavity and can be accessed easily with its knob control
Convection function
Interior fan option offers more even convection heating, ideal for faster defrosting large dishes. Combine with the bake or broil function
LP convertible
Unit comes set for natural gas but can be converted aftermarket without a kit
Broiler pan included
Porcelain tray with removable metal grate
Electronic ignition
Safer operation with a 115V cord included
Thermocouple flame failure protection
Automatically turns gas off if flame is extinguished

SPECIFICATIONS

Overview
Height of Cabinet 27.0" (69 cm)
Width 29.5" (75 cm)
Depth 22.63" (57 cm)
Depth with Handle 24.63" (63 cm)
Depth with door at 90° 39.75" (101 cm)
Capacity 3.0 cu.ft. (85 L)
Door Stainless Steel
Cabinet Stainless Steel
US Electrical Safety CSA
Amps 15.0
Voltage/Frequency 115 V AC/60 Hz
Weight 144.0 lbs. (65 kg)
Shipping Weight 149.0 lbs. (68 kg)
Parts & Labor Warranty 1 Year
Gas Walloven
Ignition Spark
LP Convertible Yes
Oven Capacity 3.0
Controls Dial
Oven Light Yes
Cooking Timer Yes
Cleaning Type Manual
Oven Rack Qty 3
Oven Window Yes
Interior Height 13.75" (35 cm)
Interior Width 23.0" (58 cm)
Interior Depth 16.0" (41 cm)
Cutout Height 26.63" (68 cm)
Cutout Width 28.0" (71 cm)
Cutout Depth 24.0" (61 cm)

DOWNLOADS

Download
BROCHURE w/ DRAWINGS
SGWO30SS.pdf
Download
TECHNICAL DRAWING (.dwg)
SGWO30SS_GAS_WALLOVEN__A-C_2010_.dwg


California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice
