MRF433ES

45.0" H x 18.75" W x 20.25" D

(114cm H x 48cm W x 51cm D)

OVERVIEW

Combination refrigerator-freezer-microwave serves all your kitchen needs in a slim 19 inch wide fit
Fully featured microwave oven with touchpad controls
Ships fully assembled
Electrical allocator box protects unit from circuit breaks by limiting power usage to 10 amps
Save time and energy with low maintenance automatic defrost

SPECIFICATIONS

Overview
Height of Cabinet	45.0" (114 cm)
Width	18.75" (48 cm)
Depth	20.25" (51 cm)
Capacity	3.6 cu.ft. (102 L)
Defrost Type	Automatic
Door	Black
Cabinet	Black
US Electrical Safety	UL
Weight	140.0 lbs. (64 kg)
Shipping Weight	145.0 lbs. (66 kg)
Parts & Labor Warranty	1 Year
Microwave-Refrigerator
Refrigerator Included	FF433ES
Refrigerator Door Swing	RHD
Reversible	Yes
Adjustable Shelves	Yes
Shelf Type	Wire
Shelf Qty	2
Crisper Qty	1
Crisper Finish	Transparent
Crisper Cover	Glass
Full Door Shelves	3
Thermostat Type	Dial
Refrigerant Type	R134a
High Side PSI	235.0
Low Side PSI	140.0
Level Legs	2
Microwave Controls	Digital
Specialized Cooking Buttons	Yes

AVAILABLE UPGRADES

Exterior

LHD - Left hand door swing

Door reversal to left hand swing

Latch for door

Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.

California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

WHERE TO BUY

DESCRIPTION

SUMMIT offers the industry's widest variety of refrigerator-microwave combination units, with sizes that fit your space and designs to serve your needs.

Model MRF433ES combines a mid-sized microwave with SUMMIT's popular compact ENERGY STAR certified FF433ES refrigerator-freezer. The complete unit has a conveniently slim under 19" width for an easy fit in any tight setting, with a black exterior to suite all kitchens. A reversible door with door storage for large bottles adds placement flexibility.

Automatic defrost operation saves users the work and mess of the manual defrosting process. Additional features include a clear crisper, adjustable thermostat, and adjustable shelves.

The MRF433ES also includes a touchpad microwave fully featured for easy heating. One-touch cook options and variable controls allow easy use.

All of SUMMIT's combination refrigerator-microwaves are shipped fully assembled and ready to use. Plug the microwave, refrigerator-freezer, and a third appliance (such as a coffee maker) into our power allocator box and use its cord for safe one-plug operation. This system protects your circuit breaker and power line by limiting overall power use to 10 amps.

In addition to those models listed in our MRF series, SUMMIT can custom-build refrigerator-microwave combination units to your individual specifications. Contact us today for more information.

FEATURES

Thin-line design
Limited space is no problem for our thin-line models, designed specifically for those hard-to-fit spots

SM902BL microwave oven
Touchpad mid-sized microwave with one-touch cook options and variable controls

FF433ES Refrigerator-freezer
Automatic defrost ENERGY STAR qualified refrigerator-freezer includes deluxe interior with crisper, adjustable shelves, and door storage

Black exterior
Jet black finish on both refrigerator-freezer and microwave

Reversible door
User reversible door swing on the refrigerator

Allocator box
Plug the refrigerator-freezer, microwave, and a third appliance into this allocator box for safe operation that limits total power consumption to 10 amps

Ships fully assembled
No assembly required before use

Stainless steel option
Substitute the FF433ESSS, FF433ESSSHV, or the FF433ESSSTB, identical refrigerator-freezers with stainless steel doors

SPECIFICATIONS

Overview
Height of Cabinet	45.0" (114 cm)
Width	18.75" (48 cm)
Depth	20.25" (51 cm)
Capacity	3.6 cu.ft. (102 L)
Defrost Type	Automatic
Door	Black
Cabinet	Black
US Electrical Safety	UL
Weight	140.0 lbs. (64 kg)
Shipping Weight	145.0 lbs. (66 kg)
Parts & Labor Warranty	1 Year
Microwave-Refrigerator
Refrigerator Included	FF433ES
Refrigerator Door Swing	RHD
Reversible	Yes
Adjustable Shelves	Yes
Shelf Type	Wire
Shelf Qty	2
Crisper Qty	1
Crisper Finish	Transparent
Crisper Cover	Glass
Full Door Shelves	3
Thermostat Type	Dial
Refrigerant Type	R134a
High Side PSI	235.0
Low Side PSI	140.0
Level Legs	2
Microwave Controls	Digital
Specialized Cooking Buttons	Yes

AVAILABLE UPGRADES

Exterior

LHD - Left hand door swing

Door reversal to left hand swing

Latch for door

Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
