20" Wide All-Freezer

SKU: FS407L
Slim 20" fit with interior basket drawers for optimum cold storage
DISCONTINUED- REPLACED BY FS407LW
34.0" H x 19.25" W x 21.38" D
(86cm H x 49cm W x 54cm D)

Overview
Height of Cabinet 33.5" (85 cm)
Height to Hinge Cap 34.0" (86 cm)
Width 19.25" (49 cm)
Depth 21.38" (54 cm)
Depth with Handle 23.0" (58 cm)
Depth with door at 90° 39.5" (100 cm)
Capacity 2.8 cu.ft. (79 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.6
Voltage/Frequency 115 V AC/60 Hz
Weight 57.0 lbs. (26 kg)
Shipping Weight 60.0 lbs. (27 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101022123
Freezer
Door Swing RHD
Reversible Yes
Interior Height 26.38" (67 cm)
Interior Width 14.0" (36 cm)
Interior Depth 16.75" (43 cm)
Thermostat Type Dial
Refrigerant Type R600a
Refrigerant Amount 1.23 oz.
High Side PSI 125.0
Low Side PSI 68.0
Level Legs 2
Interior Drawers Yes
Drawers Qty 4

Exterior
Alarm/Thermometer - Factory-installed alarm with external temperature readout
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
CAS3 3" casters
3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad - AC powered keypad lock
Keypad door lock powered by appliance power cord for keyless security
KEYPAD - Battery-powered keypad door lock
Battery-powered keypad door lock installed for keyless security

Slim 20" width

2.8 capacity inside a slim footprint

Fully finished white cabinet

Allows the unit to be used freestanding

Factory installed lock

Top-mounted for convenient security

Reversible door

Keep your options flexible with a reversible door that is easy to switch when your arrangement changes

Hospital grade cord with 'green dot' plug

Secure three-pronged cord for added unit safety

Manual defrost

Efficient performance with reliable temperature stability

-20º capable

Low temperature capability ideal for certain sensitive items

Pull-out drawers

Four clear baskets for convenient and separated storage

Adjustable thermostat

Rear mounted to prevent accidental adjustments

Flat door liner

Easy to clean, with more depth for storage

100% CFC Free

Environmentally friendly design with no ozone-damaging chemicals

Matching refrigerator available

Pair with FF511L all-refrigerator for a complete matching set

Accucold by Summit Appliance offers a quality selection of 20" wide low temperature all-freezers with the counter height FS407L series.

The FS407L is a white counter height all-freezer, with manual defrost operation and 2.8 cu.ft. capacity. Designed to operate colder than normal household freezers (-20ºC), the FS407L is ideal for general purpose storage applications. Four pull-out drawers with clear fronts offer convenient storage solutions. The adjustable thermostat is located in the rear of the model. This model has a reversible door with a factory-installed lock, top-mounted for added convenience.

Sized just under 20" wide, the freestanding FS407L can be paired with our FF511L auto defrost all-refrigerator to create a matching set. For a built-in version of this model, see the FS407LBI.

Download
BROCHURE w/ DRAWINGS
FS407L.pdf
Download
TECHNICAL DRAWING (.dwg)
FS407L_FS408BLFRE.A-C2000.dwg

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
