24" Wide All-Refrigerator, ADA Compliant
3 to 5 days
ADA
*Additional features may vary
(82cm H x 60cm W x 58cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 23.0" (58 cm) |
| Depth with door at 90° | 45.38" (115 cm) |
| Capacity | 5.8 cu.ft. (164 L) |
| Defrost Type | Automatic |
| Door | Stainless Steel |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Energy Usage/Year | 280.0kWh/year |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101069272 |
|
Refrigerator Features
|
|
| Door Swing | RHD |
| Reversible | Yes |
| Crisper Qty | 1 |
| Crisper Finish | Opaque |
| Crisper Cover | Glass |
| Shelf Type | Glass |
| Shelf Qty | 3 |
| Full Door Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Wine Bottle Shelves | Yes |
| Thermostat Type | Dial |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.64oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Interior Light | Yes |
|
Dimensions
|
|
| Interior Height | 26.25" (67 cm) |
| Interior Width | 21.0" (53 cm) |
| Interior Depth | 18.0" (46 cm) |
| Compressor Step Height | 5.5" (14 cm) |
| Compressor Step Width | 21.0" (53 cm) |
| Compressor Step Depth | 6.0" (15 cm) |
AVAILABLE UPGRADES
| Exterior | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||
| Lock | ||||||||||
|
||||||||||
| Interior | ||||||||||
|
||||||||||
| Door | ||||||||||
|
FEATURES
Freezerless refrigerator designed and manufactured in Europe for residential use
European-made collection for recessed installation featuring large capacity interiors, ENERGY STAR certified performances, and versatile style
Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs
32" height to fit under lower ADA compliant counters
Less than 24" wide with a full 5.8 cu.ft. capacity
Durable design with lasting elegance
Brushed stainless steel handle with a thin 14mm diameter is mounted horizontally across the door for a sleek look
Reduced maintenance with auto defrost system
Cold wall design with hidden evaporator and seamless interior
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
Store tall bottles and condiments right on the door for convenient access
Get the longest life and best taste out of produce by storing greens in a convenient slide drawer
Removable scalloped wine shelf is included to store champagne and wine bottles
Automatically illuminates when you open the door
Dial thermostat located inside for easy temperature management
User-reversible door swing for added flexibility
Environmentally friendly design without ozone-damaging chemicals
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
DESCRIPTION
Summit's Peak24 series of undercounter European-made refrigeration features energy efficient, ADA height choices that offer the largest capacity in the industry. Sized with a 24" footprint and 32" height, model FF63BKSSHHADA is an ENERGY STAR certified all-refrigerator designed for residential use, with a lower height ideal for ADA compliant settings. The stainless steel wrapped door is user-reversible and includes a thin horizontally mounted handle that matches many popular styles of cabinet. The cabinet and kickplate feature a jet black finish. With a full 5.8 cu.ft. interior, the Peak24 series offers a higher storage capacity than other counter height units in the market. Inside, the FF63BKSSHHADA utilizes automatic defrost operation to ensure minimum user maintenance. The 5.8 cu.ft. interior offers more storage space than most models in this size class. Adjustable glass shelves ensure spill-proof storage, while a large crisper drawer is ideal for keeping produce at its best. A removable wine shelf lets you keep bottles securely in place. The door includes three storage racks for condiments and tall bottles. The seamless interior also features a dial thermostat and automatic light. The FF63BKSSHHADA is UL listed for residential use. With its large capacity and user-friendly features, this freezerless refrigerator is a convenient option for homes, offices, schools, and other settings in need of reliable cold storage. Additional choices are available in standard counter height, as well as with freezer compartments (model CT663BKSSHHADA). Browse the full Summit catalog to discover the perfect appliance for your refrigeration needs.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
