24" Wide All-Refrigerator

SKU: FF61WSSHV

Made in Europe with a large 5.8 cu.ft. interior that offers maximum storage capacity for 24 inch spaces

Estimated Time to Ship:

3 to 5 days

Find a dealer

Height:
Standard ADA

Refrigerator Type:
With Freezer All-Refrigerator

Color: Stainless Steel/White

*Additional features may vary

Add a naturally antimicrobial copper handle for added protection against germs and bacteria.

This item can be ordered in one of our new vibrant door finishes: cobalt blue, lavender purple, emerald green, or saffron gold. Click the icon to explore our new palette!

33.5" H x 23.63" W x 23.0" D
(85cm H x 60cm W x 58cm D)

Overview
Nominal Height	34.0" (86 cm)
Height of Cabinet	33.5" (85 cm)
Nominal Width	24.0" (61 cm)
Width	23.63" (60 cm)
Nominal Depth	23.0" (58 cm)
Depth	23.0" (58 cm)
Depth with door at 90°	45.38" (115 cm)
Capacity	5.8 cu.ft. (164 L)
Defrost Type	Automatic
Door	Stainless Steel
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Energy Usage/Year	280.0kWh/year
Amps	1.4
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101069852
Refrigerator Features
Door Swing	RHD
Reversible	Factory Reversible
Crisper Qty	1
Crisper Finish	Opaque
Crisper Cover	Glass
Shelf Type	Glass
Shelf Qty	3
Full Door Shelf Qty	3
Adjustable Shelves	Yes
Wine Bottle Shelves	Yes
Thermostat Type	Dial
Fan Type	Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.64oz.
High Side PSI	180.0
Low Side PSI	80.0
Level Legs Qty	4
Interior Light	Yes
Dimensions
Interior Height	26.25" (67 cm)
Interior Width	21.0" (53 cm)
Interior Depth	18.0" (46 cm)
Compressor Step Height	5.5" (14 cm)
Compressor Step Width	21.0" (53 cm)
Compressor Step Depth	6.0" (15 cm)

Door

CDP-Lavender purple door wrap Lavender purple door wrap with horizontally mounted stainless steel handle and matching kickplate	CDB-Cobalt blue door wrap Cobalt blue door wrap with horizontally mounted stainless steel handle and matching kickplate
CDY-Saffron gold door wrap Saffron gold door wrap with horizontally mounted stainless steel handle and matching kickplate	CDG-Emerald green door Emerald green door wrap with horizontally mounted stainless steel handle and matching kickplate
STO-Step-To-Open Door Pedal Step-to-open door pedal allows hands-free access to open the door 90 degrees

Handle

TBC Copper Towel Bar Handle Upgrade Change this handle to a 12" vertically mounted towel bar style handle made from pure copper for antimicrobial protection

Exterior

HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix	SSK - Stainless steel kickplate Stainless steel kickplate factory installed
Latch - Factory-installed door latch requires manual release to open unit Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles (NOTE: latch adds 1 1/2" of width to unit)	LHD - Left hand door swing Door reversal to left hand swing
SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option	SS Hinges Stainless steel top and bottom hinges
Alarm/Thermometer - Factory-installed alarm with external temperature readout Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	CAS3 3" casters 3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management	Legs to raise unit height 6" high leveling legs
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Interior

FCGP internal fan with gel packs Internal fan with gel packs included for a stabilized interior

Lock

AC Keypad - AC powered keypad lock Keypad door lock powered by appliance power cord for keyless security	KEYPAD - Battery-powered keypad door lock Battery-powered keypad door lock installed for keyless security
L-SideLock Add a single keyed lock located on the door's side (NOTE: side lock adds 1" to overall unit width and comes in white)

24" Wide European All-Refrigerator

Freezerless refrigerator designed and manufactured in Europe for residential use

Peak24 Series

European-made collection featuring large capacity interiors, ENERGY STAR certified performances, and versatile style

ENERGY STAR certified

Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs

Slim undercounter dimensions

Less than 24" wide with a full 5.8 cu.ft. capacity

Fully finished white cabinet

Allows the unit to be used freestanding

Stainless steel wrapped door

Durable design with lasting elegance

Professional stainless steel handle

Thin 14mm diameter on stainless steel handle, mounted vertically for a sleek look

Automatic defrost

Reduced user maintenance with automatic defrost operation

Adjustable glass shelves

Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup

Door shelves

Keep tall bottles and condiments right on the door for convenient access

Crisper drawer

Get the longest life and best taste out of produce by storing greens in lower slide drawer

Wine shelf

Removable scalloped wine shelf is included to store champagne and wine bottles

Interior light

Automatically illuminates when the door is opened

Hidden evaporator

Cold wall design with hidden evaporator and seamless interior

One piece interior liner

Simple cleanup with a seamless liner that won't hold a mess in hidden crevices

Adjustable thermostat

Dial thermostat located inside for easy temperature management

100% CFC free

Environmentally friendly design does not contain ozone-damaging chemicals

CARB Compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Summit's Peak24 series of undercounter European-made refrigeration features energy efficient, counter height choices that offer the largest capacity in the industry.

Sized with a 24" footprint, model FF61WSSHV is an ENERGY STAR certified all-refrigerator designed for residential use. The stainless steel wrapped door comes with a pre-installed thin handle that offers an elegant look to match many popular styles of cabinetry. The cabinet and kickplate feature a clean white finish.

With a full 5.8 cu.ft. interior, the Peak24 series offers a higher storage capacity than other counter height units in the market. Inside, the FF61WSSHV utilizes automatic defrost operation to ensure minimum user maintenance. The 5.8 cu.ft. interior offers more storage space than most models in this size class. Adjustable glass shelves ensure spill-proof storage, while a large crisper drawer is ideal for keeping produce at its best. A removable wine shelf lets you keep bottles securely in place. The door includes three storage racks for condiments and tall bottles. The seamless interior also features a dial thermostat and automatic light.

The FF61WSSHV is UL listed for residential use. With its large capacity and user-friendly features, this freezerless refrigerator is a convenient option for homes, offices, schools, and other settings in need of reliable cold storage. Additional choices are available in lower ADA height, as well as with freezer compartments (model CT661WSSHV). Browse the full Summit catalog to discover the perfect appliance for your refrigeration needs.

BROCHURE
FF61WSSHV.pdf

USE & CARE
FF61WBI_FF63BKBI_Use___Care.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
