24" Wide Top Mount Refrigerator-Freezer

SKU: FF1142PL
ENERGY STAR certified for efficient performance and fully featured with glass shelves and generous door storage
Estimated Time to Ship:

Next day shipping

Door Swing:
RHD LHD

*Additional features may vary

This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.
66.75" H x 23.5" W x 25.5" D
(170cm H x 60cm W x 65cm D)

Overview
Nominal Height 67.0" (170 cm)
Height of Cabinet 66.75" (170 cm)
Nominal Width 24.0" (61 cm)
Width 23.5" (60 cm)
Width with Door Open 24.63" (63 cm)
Nominal Depth 26.0" (66 cm)
Depth 25.5" (65 cm)
Depth with door at 90° 50.0" (127 cm)
Capacity 11.6 cu.ft. (328 L)
Defrost Type Frost-Free
Door Stainless Look
Cabinet Gray
US Electrical Safety CSA
Canadian Electrical Safety CSA-C
Energy Usage/Year 308.0kWh/year
Amps 2.5
Voltage/Frequency 115 V AC/60 Hz
Weight 121.0 lbs. (55 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101103600
Refrigerator-Freezer
Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Plastic
Interior Light Yes
Refrigerator - Interior Height 40.63" (103 cm)
Refrigerator - Interior Width 20.5" (52 cm)
Refrigerator - Interior Depth 19.5" (50 cm)
Refrigerator - Shelf Type Glass
Refrigerator - Shelf Qty 3
Refrigerator - Full Door Shelves 3
Freezer - Interior Height 16.75" (43 cm)
Freezer - Interior Width 17.5" (44 cm)
Freezer - Interior Depth 15.75" (40 cm)
Freezer - Shelf Type Glass
Freezer - Full Door Shelves 2
Thermostat Type Dial
Refrigerant Type R600a
Refrigerant Amount 1.2 oz.
High Side PSI 250.0
Low Side PSI 88.0
Level Legs 2
Interior Height - Drawer 1 9.5" (24 cm)
Interior Width - Drawer 1 20.5" (52 cm)
Interior Depth - Drawer 1 16.0" (41 cm)
Compressor Step Height 9.5" (24 cm)
Compressor Step Width 20.5" (52 cm)
Compressor Step Depth 6.0" (15 cm)
Sound Level 32.6 dB

Exterior
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles (NOTE: latch adds 1 1/2" of width to unit)
LHD - Left hand door swing
Door reversal to left hand swing

24" Wide Top Mount Refrigerator-Freezer

Slim-fitting design ideal for smaller kitchens

ENERGY STAR-certified

Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs

Frost-free operation

No-frost convenience for reduced user maintenance

Thin-line design

Limited space is no problem for our thin-line models, designed specifically for those hard-to-fit spots

Large capacity

11.5 cu.ft. interior offers generous storage in a slim fit

Stainless steel look

Doors offer the look of stainless steel complete with a vertical grain, but the easier cleanability of a fingerprint-resistant steel finish

Adjustable glass shelves

Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Crisper drawer

Get the longest life and best taste out of produce by storing it in a convenient slide drawer

Door storage

Multiple door shelves in both the refrigerator and freezer compartments offer convenient storage for condiments and bottles

Adjustable door storage

Store tall bottles and condiments right on the door for convenient access

Full freezer shelf

Adjustable glass shelf included to accommodate a variety of sizes inside the top freezer compartment

Adjustable thermostat

Dial thermostat offers easy temperature management

Interior light

Automatically illuminates when you open the door

Gray cabinet

Textured gray cabinet allows the unit to be used freestanding

Reversible doors

User-reversible door swing for added flexibility

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

CARB Compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Summit Appliance manufactures the industry's most extensive collections of frost-free refrigerator-freezers in unique footprints for apartments, ADUs, and smaller kitchens.

The ENERGY STAR-certified FF1142PL offers over 11 cu.ft. of storage capacity in a slim fit under 24" wide and 66.75" high. The reversible doors feature a stainless steel look with a vertical grain, perfect for elevating your space without the hassle of fingerprint stains. This unit has a gray cabinet that allows for freestanding placement. The rear is sealed with no exposed coils for a better fit and easier cleanup.

Inside, the FF1142PL comes fully featured for convenient storage. The refrigerator section includes three adjustable spill-proof glass shelves and a clear crisper for optimum produce storage. The unit's door storage consists of a large bottom rack to hold half-gallon containers and two removable door racks offer flexible condiment and bottle storage. The fresh food section features an intuitive dial thermostat and an automatic interior light. The large freezer compartment includes its own slide thermostat, two door shelves, and an adjustable glass shelf.

Conveniently featured and perfectly sized, the FF1142PL is the ideal choice for apartments and other smaller kitchens looking for an energy-efficient refrigerator-freezer.

Download
BROCHURE w/ DRAWINGS
FF1142PL.pdf
Download
TECHNICAL DRAWING (.dwg)
FF1142PL.dwg
Download
ASSEMBLY DRAWING
FF1142PL-Assembly.pdf
Energy Guide

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
