24" Wide Refrigerator-Freezer

SKU: CT701W
Made in North America and featuring a full 6 cu.ft. storage capacity
DISCONTINUED- REPLACED BY CT661W
33.5" H x 23.75" W x 26.0" D
(85cm H x 60cm W x 66cm D)

Overview
Height of Cabinet 33.5" (85 cm)
Height to Hinge Cap 33.5" (85 cm)
Width 23.75" (60 cm)
Depth 26.0" (66 cm)
Depth with door at 90° 48.25" (123 cm)
Capacity 6.0 cu.ft. (170 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety UL
Energy Usage/Year 265.0kWh/year
Voltage/Frequency 115 V AC/60 Hz
Weight 99.0 lbs. (45 kg)
Shipping Weight 102.0 lbs. (46 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101038315
Refrigerator-Freezer
Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Crisper Qty 1
Crisper Finish Opaque
Crisper Cover Glass
Interior Light Yes
Refrigerator - Interior Height 22.5" (57 cm)
Refrigerator - Interior Width 20.75" (53 cm)
Refrigerator - Interior Depth 19.5" (50 cm)
Refrigerator - Shelf Type Wire
Refrigerator - Shelf Qty 2
Refrigerator - Full Door Shelves 3
Refrigerator - Temperature Range 36 to 46 °F
Freezer - Interior Height 6.25" (16 cm)
Freezer - Interior Width 20.75" (53 cm)
Freezer - Interior Depth 19.5" (50 cm)
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 3.0 oz.
High Side PSI 235.0
Low Side PSI 140.0
Level Legs 2

Exterior
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Alarm/Thermometer - Factory-installed alarm with external temperature readout
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad - AC powered keypad lock
Keypad door lock powered by appliance power cord for keyless security
KEYPAD - Battery-powered keypad door lock
Battery-powered keypad door lock installed for keyless security

Slim counter height dimensions

Less than 24" wide

Adjustable shelves

Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Reversible door

User-reversible door swing for added flexibility

Adjustable thermostat

Dial thermostat for easy temperature management

Door storage

Store tall bottles and condiments right on the door for convenient access

Fruit and vegetable crisper

Get the longest life and best taste out of produce by storing greens in a convenient slide drawer

Interior light

Automatically illuminates when you open the door

Manual defrost

Static cooling system

Residential unit

Meets current DOE standards for energy use in residential applications

Fully finished cabinet

Allows the unit to be used freestanding

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

Solid construction meets great value in SUMMIT's perfectly sized CT701W refrigerator-freezer.

This compact unit offers a full 6 cu.ft. of capacity, with manual defrost operation to conserve energy and lower operating cost. Adjustable wire shelves and door racks let you get the most out of storage, with a bottom crisper to maximize produce life. The user-reversible door swing offers added convenience.

Made in North America, the CT701W is perfect for short-term residence hotels or barracks that require an easy fitting, reliable refrigerator-freezer without some of the upgraded features of our more expensive units.

Download
BROCHURE w/ DRAWINGS
CT701W.pdf
Download
TECHNICAL DRAWING (.dwg)
CT70_ARCT.dwg
Download
MSDS INFORMATION
MSDS_R134a_PS.pdf
Download
USE & CARE
CT701W_Manual.pdf
Energy Guide

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
