24" Wide Built-In Wine/Beverage Center

SKU: CLFD243WBV
French door swing with seamless stainless steel trim for an elegant look under the counter
Estimated Time to Ship:

Next day shipping

Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.
33.75" H x 23.38" W x 22.88" D
(86cm H x 59cm W x 58cm D)

Overview
Height of Cabinet 33.75" (86 cm)
Width 23.38" (59 cm)
Depth 22.88" (58 cm)
Depth with Handle 24.63" (63 cm)
Depth with door at 90° 35.25" (90 cm)
Capacity 5.1 cu.ft. (144 L)
Bottles 17 bottles
Defrost Type Automatic
Door Glass/SS
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Energy Usage/Year 400.0kWh/year
Amps 1.0
Voltage/Frequency 115 V AC/60 Hz
Weight 108.0 lbs. (49 kg)
Shipping Weight 118.0 lbs. (54 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101058511
Wine Cellar
Number of Zones 2
Door Swing French
Adjustable Shelves Yes
Shelf Type Glass and Wood
Shelf Qty 8
Thermostat Type Digital
Interior Light Yes
Fan Type Interior
Refrigerant Type R600a
Refrigerant Amount 1.06 oz.
High Side PSI 270.0
Low Side PSI 105.0
Interior Height 1 25.25" (64 cm)
Interior Width 1 8.38" (21 cm)
Interior Depth 1 17.5" (44 cm)
Compressor Step Height 4.38" (11 cm)
Compressor Step Width 8.38" (21 cm)
Compressor Step Depth 5.0" (13 cm)
Level Legs 2
Temperature Range 36-43°F (left zone); 41-68°F (right zone)
Interior Height 2 25.25" (64 cm)
Interior Width 2 8.38" (21 cm)
Interior Depth 2 17.5" (44 cm)
Sabbath Mode Yes

Door
T3F Door Tint
Reflective door tint in light blue finish for medium energy savings
T4 Door Tint
Neutral door tint in light smoke finish for moderate energy savings
T1SF Door Tint
Reflective door tint in dark smoke finish for maximum energy savings on full-size and two-door models
T4F Door Tint
Neutral door tint in light smoke finish for moderate energy savings
T2F Door Tint
Tinted door in reflective deep blue finish with high energy savings

Built-in capable

Make the best use of space by installing your appliance under the counter

Dual section design

Store beverages in the left section with a temperature range of 36-43°F and wine in the right section with a temperature range of 41-68°F

Factory-installed lock

Keyed lock for each section ensure a secure interior

Digital display

Electronic controls for precise temperature management

Digital thermostat

Temperature readout can be shown in Celsius or Fahrenheit

Stainless steel trimmed wooden shelves

Five wooden shelves with a black finish feature stainless steel trim for an added touch of elegance

Versatile storage

Wine compartment can hold up to 17 standard 750ml Bordeaux or Burgundy style bottles (3 on each shelf and 2 on the slotted bottom)

Adjustable glass shelves

Three slide-out shelves offer attractive and convenient storage for beverages

Professional handles

Two vertically mounted handles in brushed stainless steel for added elegance

Stainless steel kickplate

Completes the professional look down to the toe kick

Temperature alarm

Audibly alerts if the interior temperature rises or falls out of the recommended storage range

Open door alarm

Audible alarm will sound if the door is left ajar

Fan-forced cooling

Internal fans in each section ensure the interior is evenly cooled from top to bottom

Automatic defrost

Reduced maintenance and steady temperature performance

Sealed back

Space saving design with easier cleanability

Sabbath mode

Optional setting lets you disable the lighting and alarms during periods of religious observance

Temperature memory function

Unit will retain its last settings when power is restored in the event of power loss

Full finished black cabinet

Allows the unit to be used freestanding

Anti-tip bracket

Bracket (included) helps prevent tipping for added safety

Commercial design

Meets UL-471

100% CFC free

Environmentally friendly design with no ozone-damaging chemicals

The SUMMIT Classic Collection features deluxe undercounter appliances designed to bring modern luxury into the home.

The CLFD243WBV is an undercounter wine and beverage center with two independent temperature zones. Two glass doors feature a French opening design, providing a dramatic presentation for your collection. Seamless stainless steel trim blends into the glass, while pro-style handles and a designer kickplate complete the modern look. The front-breathing design allows the CLFD243WBV to be built-in under counters, while the fully finished black cabinet also enables freestanding use. At just under 24" wide and deep, this unit is perfectly sized to fit common wet bar cutouts. The sealed back adds to the easy cleanability.

Inside, the CLFD243WBV features two zones for the proper storage of wine and beverages. The left zone includes three adjustable glass shelves for spill-proof convenience. The right zone contains five wooden shelves in a black finish, each with stainless steel trim for an elegant look. The wine section can accommodate up to 17 Bordeaux or Burgundy style bottles. The interior digital control panel includes a digital thermostat for easy and intuitive operation, with a readout in Celsius or Fahrenheit. White LED lighting in each section offers an elegant yet energy-efficient accent in the jet black interior. Additional features include a temperature memory function to restore set temperature in the case of power loss and Sabbath mode which disables certain functions during periods of religious observance. A built-in alarm audibly warns if the door is left ajar or if the unit rises or falls out of the recommended temperature range. Two level legs help to balance the unit on uneven surfaces.

Fully featured for user convenience and beautifully styled for the home, the CLFD243WBV offers the perfect storage solution for under the counter.

Note: This unit comes with an anti-tip bracket that should be installed to help prevent tipping of the unit for added safety.



Download
BROCHURE w/ DRAWINGS
CLFD243WBV.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
