BIM25

No drain required

25.25" H x 15.25" W x 18.25" D

(64cm H x 39cm W x 46cm D)

OVERVIEW

  • Compact size for easy placement
  • Flexible design allows built-in or freestanding use
  • Professional exterior for modern look
  • Produces up to 12 lbs. of crescent-shaped ice in a day cycle
  • No drain required for operation

SPECIFICATIONS

Overview
Height of Cabinet 24.75" (63 cm)
Height to Hinge Cap 25.25" (64 cm)
Width 15.25" (39 cm)
Depth 18.25" (46 cm)
Depth with door at 90° 31.75" (81 cm)
Capacity 1.0 cu.ft. (28 L)
Defrost Type Manual
Door Stainless Steel
Cabinet Black
US Electrical Safety UL
Canadian Electrical Safety ULC
Amps 1.7
Voltage/Frequency 115 V AC/60 Hz
Weight 50.0 lbs. (23 kg)
Shipping Weight 53.0 lbs. (24 kg)
Estimated Time to Ship Next day shipping
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Icemaker
Door Swing RHD
Reversible Factory Reversible
Daily Ice Production 12.0 lbs. (5 kg)
Ice Storage Capacity 12.0 lbs. (5 kg)
Ice Shape Crescent
Number of Ice Cube Sizes 1
Refrigerant Type R134a
Refrigerant Amount 2.12 oz.
High Side PSI 250.0
Low Side PSI 110.0
Interior Height 11.5" (29 cm)
Interior Width 10.0" (25 cm)
Interior Depth 12.63" (32 cm)
Level Legs 2

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
California residents:
Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.

WHERE TO BUY

Invalid Format

DESCRIPTION

SUMMIT BIM25 is a compact icemaker with a modern look and convenient design.

Sized at 15" wide, the BIM25 can produce up to 12 pounds of crescent-shaped ice per day, storing it in a removable insulated bin. This unit features a fully finished black cabinet with a stainless steel door for an attractive look. The front-breathing system allows the unit to be installed under counters. A side defrost drain is included for easier cleaning. No drain or pump is required for use. This unit includes a connection hose, but other hardware must be supplied by your plumber.

With its compact size and easy operation, the BIM25 is the perfect unit for home bars, apartment units, yacht kitchens, and other settings looking to offer a reliable icemaker in attractive style.

FEATURES

Built-in capable
Make the best use of space by installing your icemaker under the counter and flush with other cabinets
Mid-sized capacity
Produces and stores up to 12 pounds of ice per day cycle
Insulated storage bin
Ice stays solid longer in this cold-protected bin
Manual defrost
Side drain included for easier cleanup
Ice scoop included
Large plastic ice scoop included for your convenience
Fully finished cabinet
Allows the icemaker to be used freestanding
100% CFC free
Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet 24.75" (63 cm)
Height to Hinge Cap 25.25" (64 cm)
Width 15.25" (39 cm)
Depth 18.25" (46 cm)
Depth with door at 90° 31.75" (81 cm)
Capacity 1.0 cu.ft. (28 L)
Defrost Type Manual
Door Stainless Steel
Cabinet Black
US Electrical Safety UL
Canadian Electrical Safety ULC
Amps 1.7
Voltage/Frequency 115 V AC/60 Hz
Weight 50.0 lbs. (23 kg)
Shipping Weight 53.0 lbs. (24 kg)
Estimated Time to Ship Next day shipping
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Icemaker
Door Swing RHD
Reversible Factory Reversible
Daily Ice Production 12.0 lbs. (5 kg)
Ice Storage Capacity 12.0 lbs. (5 kg)
Ice Shape Crescent
Number of Ice Cube Sizes 1
Refrigerant Type R134a
Refrigerant Amount 2.12 oz.
High Side PSI 250.0
Low Side PSI 110.0
Interior Height 11.5" (29 cm)
Interior Width 10.0" (25 cm)
Interior Depth 12.63" (32 cm)
Level Legs 2

AVAILABLE UPGRADES

Exterior
Latch for door
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing

DOWNLOADS

Download
BROCHURE w/ DRAWINGS
BIM25.pdf
Download
TECHNICAL DRAWING (.dwg)
BIM25_ICE_MAKER__A-C_2000_.dwg
Download
USE & CARE
BIM25_manual.pdf
