WNM2107
SHARE THIS PRODUCT
Pinterest E-mail a Friend Print

SPECIFICATIONS

Overview
Height 40.0"
Width 30.0"
Depth 24.0"
Door White
Cabinet White
Weight 165.0 lbs.
Shipping Weight 175.0 lbs.
Parts & Labor Warranty 1 Year
Gas Range
Ignition Spark
LP Convertible With KitLP Accessory
Oven Capacity 3.7cu.ft
Cooktop Surface Porcelain
Burner Type Open
Number of Burners 4
Burner #1 BTU 9000.0
Burner #2 BTU 9000.0
Burner #3 BTU 9000.0
Burner #4 BTU 9000.0
Burner Controls Dial
Oven Controls Dial
Backguard Yes
Oven Interior Height 14.0"
Oven Interior Width 24.0"
Oven Interior Depth 19.0"
Broiler Location Below Oven
Broiler Door White
Oven Door White

AVAILABLE UPGRADES

Exterior
LP Conversion
Have this range factory converted to LP gas. KIT LP is included

WNM2107

Delivery
This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.

Made in the USA

40" H x 30" W x 24" D

OVERVIEW

WHERE TO BUY

Invalid Format
SUMMIT offers a wide selection of household ranges with high quality construction at superior value.

The WNM2107 is a 30" wide gas range with electronic ignition. A full oven accommodates large scale cooking and a lower broiler drawer provides even crisping. The complete porcelain and steel construction makes the WNM2107 a durable unit with classic style. Made in the USA and built for years of heavy duty cooking.

The WNM2107 replaces the WNM2103.

FEATURES

30" wide gas range
Natural gas range; can be converted to LP Gas in our shop or ordered with KIT LP for conversion
Recessed oven door
Smart design limits the depth and protects adjacent cabinets
Electronic ignition
Gas spark ignition for automatic lighting of burners
Porcelain construction
Solid porcelain range top and oven
Broiler drawer
Lower compartment for separate broiling with even heat distribution
Removable oven door and range top
White porcelain oven door and top can be removed for easier cleaning
Anti-tip bracket
Install to prevent accidents from tipping oven over
Broiler tray included
Porcelain broiler tray with grease well

DOWNLOADS

Download BROCHURE w/ DRAWINGS
WNM2107.pdf
Download TECHNICAL DRAWING (.dwg)
WNM210RANGEGASA-C2000.dwg
