20" Wide Gas Range
(102cm H x 51cm W x 61cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Height of Cabinet | 40.0" (102 cm) |
| Width | 20.0" (51 cm) |
| Depth | 24.0" (61 cm) |
| Door | White |
| Cabinet | White |
| US Electrical Safety | CSA |
| Weight | 140.0 lbs. (64 kg) |
| Shipping Weight | 145.0 lbs. (66 kg) |
| Parts & Labor Warranty | 1 Year |
| UPC | 761101060910 |
|
Gas Range
|
|
| Ignition | Spark |
| LP Convertible | With Kit LP S2 Accessory |
| Oven Capacity | 2.46 cu.ft |
| Cooktop Surface | Porcelain |
| Burner Type | Sealed |
| Number of Burners | 4 |
| Burner #1 BTU | 9100.0 |
| Burner #2 BTU | 9100.0 |
| Burner #3 BTU | 9100.0 |
| Burner #4 BTU | 9100.0 |
| Burner Controls | Dial |
| Oven Controls | Dial |
| Backguard | Yes |
| Cleaning Type | Manual |
| Oven Rack Qty | 2 |
| Oven Interior Height | 14.0" (36 cm) |
| Oven Interior Width | 16.0" (41 cm) |
| Oven Interior Depth | 19.0" (48 cm) |
| Broiler Location | Below Oven |
| Broiler Door | White |
| Oven Door | White |
AVAILABLE UPGRADES
| Exterior | |
|---|---|
|
|
| Interior | |
|
FEATURES
Apartment sized to fit in small or galley kitchens
Four 9100 BTU sealed burners for cleaner cooking
Gas spark ignition for automatic lighting of burners
White porcelain removable oven top and door
Lower compartment for separate broiling with even heat distribution
Two-piece porcelain broiler tray with grease well
To prevent accidents, knobs require a small amount of force when turning
Burners include a removable cap for easy cleaning
Smart design limits the depth and protects adjacent cabinets
Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
For LP conversion, contact our office at 718-893-3900 ext. 220
Upfront controls and easy-to-operate knobs offer easier accessibility
DESCRIPTION
SUMMIT offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens. The WTM1107S is an apartment-sized gas range sized at just 20" wide, with a generous 2.46 cu.ft oven interior that still can accommodate large trays. The broiler is located below the oven in a drop-down compartment. Four sealed 9100 BTU gas burners offer safer cleaning and cleaner cooking. This unit utilizes an electronic ignition system for added safety. The WTM1107S comes in an all-white exterior finish. Fully constructed from steel and porcelain, Summit's American-made cooking line offers long-lasting quality for the home. Additional choices are available in 24" and 30" wide fits.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
