30" Wide 4-Burner Gas Cooktop

SKU: TTL053S
Made in the USA with sealed burners and cast iron grates for a safer, cleaner cooking experience
Estimated Time to Ship:

Next day shipping; multi-piece orders may extend lead time. Call 718-893-3900 ext. 507 to discuss

Color: Black

*Additional features may vary

This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.
4.0" H x 29.75" W x 20.0" D
(10cm H x 76cm W x 51cm D)

Overview
Height of Cabinet 4.0" (10 cm)
Width 29.75" (76 cm)
Depth 20.0" (51 cm)
Cabinet Black
US Electrical Safety CSA
Canadian Electrical Safety CSA-C
Weight 27.0 lbs. (12 kg)
Shipping Weight 44.0 lbs. (20 kg)
Parts & Labor Warranty 1 Year
UPC 761101061634
Gas Cooktop
Ignition Spark
LP Convertible With Kit LP S2 Accessory
Number of Burners 4
Controls Dial
Surface Painted
Grate Material Cast Iron
Cutout Width 28.38" (72 cm)
Cutout Depth 18.63" (47 cm)
Burner #1 BTU 12000.0
Burner #2 BTU 9100.0
Burner #3 BTU 9100.0
Burner #4 BTU 5000.0
Power Cord Included Yes

Exterior
LP Conversion
Have this range factory converted to LP gas. KIT LP is included

Made in the USA

Designed and constructed domestically

Sealed Sabaf® burners

Quality burners with cast iron tops ensure lasting durability and easier cleanup

Cast iron grates

Two sets of continuous grates in heavy duty cast iron hold up to large cookware

Fits common cutouts

Designed for 28 3/8" W x 18 5/8" D cutouts for an easy fit in smaller kitchens

Power burner

Front left burner features 12,000 BTU output for powerful cooking

Simmer burner

Rear burner on right side reaches maximum of 5,000 BTUs to allow more precise heating of sensitive items

Two standard burners

Front right and rear left burners offer 9100 BTUs of cooking power to accommodate most dishes

Push-to-turn knobs

To prevent accidents, knobs require a small amount of force when turning

Recessed top

Curved design helps to contain spills on the surface for easier cleanup

Porcelain cooking surface

Black finish on scratch resistant top

Removable burner caps

Burners include a removable cap for easy cleaning

Electronic/gas spark ignition

Gas spark ignition for automatic lighting of burners

Cord included

Pre-installed 115V 3-pronged power cord

Convertible with kit

Unit is set for natural gas. To use with LP gas, order Summit Kit LP S2 accessory

Made in the U.S.A., Summit's gas cooktops offer lasting quality and reliable cooking.

The TTL053S is a 30" wide 4-burner cooktop designed for 28 3/8" W x 18 5/8" D cutouts. The scratch-resistant porcelain surface features a glossy jet black finish and recessed design to better contain spills. The side-located push-to-turn dial knobs offer easy use. Two sets of continuous cast iron grates are designed to hold up to heavy pots and pans.

Four sealed Sabaf burners with removable burner caps ensure safer and cleaner cooking. The TTL053S includes a high output 12000 BTU burner for powerful heating, conveniently located in front for easy access. The rear 5000 BTU burner is ideal for simmering at lower power or keeping food warm without overcooking. Two standard 9100 BTU burners meet most cooking needs. This unit utilizes electronic spark ignition and includes a pre-installed 3-pronged cord.

The TTL053S is set for natural gas and can be converted to propane connections with the purchase of our Kit LP S2. Additional choices are available in white and chrome, as well as in 24" and 27" wide fits. Browse our site for more.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
