SPFF51OSSSHV

This unit can be used for commercial or residential applications. It meets applicable U.S. Department of Energy (DOE) standards for both household and commercial energy usage. For information on its commercial sanitation listing, see Specifications.

True frost-free operation ensures minimum user maintenance

34.0" H x 23.63" W x 23.5" D

(86cm H x 60cm W x 60cm D)

OVERVIEW

Weatherproof construction allows safe use in the outdoors
True frost-free operation saves you maintenance by preventing icy buildup
Flexible design allows built-in or freestanding use in 24" wide spaces
Digital thermostat allows easy temperature management
304 grade stainless steel wrapped door for long-lasting luxury
Factory installed lock offers trusted security
Sleek stainless steel handle completes the look

SPECIFICATIONS

Overview
Height of Cabinet	34.0" (86 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Depth with Handle	25.35" (64 cm)
Depth with door at 90°	45.63" (116 cm)
Capacity	4.72 cu.ft. (134 L)
Defrost Type	Frost-Free
Door	Stainless Steel
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Energy Usage/Year	390.0kWh/year
Amps	2.0
Voltage/Frequency	115 V AC/60 Hz
Weight	108.0 lbs. (49 kg)
Shipping Weight	113.0 lbs. (51 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Freezer
Door Swing	RHD
Reversible	Factory Reversible
Shelf Type	Chrome
Shelf Qty	3
Adjustable Shelves	Yes
Thermostat Type	Digital
Interior Light	Yes
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	1.24 oz.
High Side PSI	270.0
Low Side PSI	106.0
Sabbath Mode	Yes

AVAILABLE UPGRADES

Exterior

Extra key Extra keys available for purchase	LHD - Left hand door swing Door reversal to left hand swing
Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.	SSK Stainless steel kickplate factory installed

California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

WHERE TO BUY

DESCRIPTION

SUMMIT SPFF51OS Series features versatile frost-free all-freezers perfectly sized and featured for convenient use in outdoor spaces.

The SPFF51OSSSHV is a 24" wide all-freezer designed for built-in or freestanding use, with a fully finished jet black cabinet and 304 grade stainless steel wrapped door. The door includes a factory installed lock and a thin stainless steel handle to complete the professional look.

Inside, the SPFF51OSSSHV is designed for true convenience and low maintenance operation. The frost-free design ensures users won't have to manually defrost the 4.72 cu.ft. interior, while adjustable shelves offer flexible storage solutions. Recessed LED lighting provides an attractive, energy efficient display. A digital thermostat (located in the unit's kickplate) makes temperature management easy and intuitive.

With solid construction and a striking design, the SPFF51OSSSHV makes an ideal finish for any outdoor kitchen. For this unit without a factory installed icemaker, see the SPFF51OSSSHVIM.

FEATURES

Weatherproof design
Designed and constructed for use in the outdoors

Frost-free operation
No-frost convenience eliminates the need to manually defrost the unit

Stainless steel wrapped door
304 grade stainless steel door stands up to the elements in style

Built-in capable
Make the best use of space by installing your freezer under the counter and flush with other cabinets

Digital thermostat
Electronic controls offer easy and intuitive temperature management

Factory installed lock
Keyed lock for a secure interior

Recessed LED light
Elegant lighting with an on/off switch located on the control panel

Adjustable shelves
Rearrange your freezer space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Professional handle
Thin (14mm diameter) stainless steel handle offers an elegant finish to the stainless steel door

Commercially listed
ETL-S listed to NSF-7 standards for use in commercial settings

Fully finished cabinet
Allows the freezer to be used as a freestanding model

100% CFC free
Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet	34.0" (86 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Depth with Handle	25.35" (64 cm)
Depth with door at 90°	45.63" (116 cm)
Capacity	4.72 cu.ft. (134 L)
Defrost Type	Frost-Free
Door	Stainless Steel
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Energy Usage/Year	390.0kWh/year
Amps	2.0
Voltage/Frequency	115 V AC/60 Hz
Weight	108.0 lbs. (49 kg)
Shipping Weight	113.0 lbs. (51 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Freezer
Door Swing	RHD
Reversible	Factory Reversible
Shelf Type	Chrome
Shelf Qty	3
Adjustable Shelves	Yes
Thermostat Type	Digital
Interior Light	Yes
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	1.24 oz.
High Side PSI	270.0
Low Side PSI	106.0
Sabbath Mode	Yes

AVAILABLE UPGRADES

Exterior

Extra key Extra keys available for purchase	LHD - Left hand door swing Door reversal to left hand swing
Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.	SSK Stainless steel kickplate factory installed
