FS408BL7SSHVADA
SHARE THIS PRODUCT
E-mail a Friend Print

SPECIFICATIONS

Overview
Height of Cabinet 32.0" (81 cm)
Height to Hinge Cap 32.5" (83 cm)
Width 19.25" (49 cm)
Depth 21.38" (54 cm)
Depth with door at 90° 39.5" (100 cm)
Capacity 2.8 cu.ft. (79 L)
Defrost Type Manual
Door Stainless Steel
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 1.6
Voltage/Frequency 115 V AC/60 Hz
Weight 64.0 lbs. (29 kg)
Shipping Weight 85.0 lbs. (39 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing RHD
Reversible Factory Reversible
Interior Height 26.38" (67 cm)
Interior Width 14.0" (36 cm)
Interior Depth 16.75" (43 cm)
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 3.0 oz.
High Side PSI 210.0
Low Side PSI 105.0
Level Legs 2
Interior Drawers Yes
Drawers Qty 4

AVAILABLE UPGRADES

Exterior
SCD Self-Closing Door
Protect interior contents and reduce energy waste with the Self Closing Door Option


California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

FS408BL7SSHVADA Matching refrigerator 1fb6556d9b0cb2e64cec9dc4031ce73c627b001b680e10e944813b0725db703e

Commercial meets nsf 57f181a562ef64be646d83b66028b1c5c2f384b45328a17b7b74a5f0cdc84c8e
This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

Slim 20" fit with interior basket drawers for optimum cold storage

32.5" H x 19.25" W x 21.38" D

OVERVIEW

WHERE TO BUY

Invalid Format
Accucold by Summit Appliance offers a quality selection of ADA compliant 20" wide commercial all-freezers with the 32" high FS408BL7ADA series.

The ETL-S listed FS408BL7SSHVADA is an all-freezer, with manual defrost operation and 2.8 cu.ft. capacity. Four pull-out drawers with clear fronts offer convenient storage solutions. The adjustable thermostat is located in the rear of the model and a hospital grade (green dot) cord offers additional safety in high traffic areas.

Designed for freestanding use, the FS408BL7SSHVADA has a black cabinet with a professional style stainless steel wrapped door and sleek handle. A top-mounted lock adds convenient security.

Sized just under 20" wide, the freestanding FS408BL7SSHVADA has a 32" height to meet ADA guidelines for lower counters. This model can be paired with the FF521BL7SSHVADA auto defrost all-refrigerator to create a matching set. For a built-in version of this model, see the FS408BLBI7SSHVADA.

FEATURES

ADA compliant
32" high meets ADA guidelines
Commercially listed
ETL-S listed to NSF standards for commercial use
Slim 20" width
2.8 cu.ft. capacity inside a slim footprint
Fully finished black cabinet
Allows the unit to be used freestanding
Stainless steel wrapped door
Durable 304 grade wrapping
Professional handle
Thin 14mm diameter on vertical stainless steel handle
Factory installed lock
Top-mounted for convenient security
Hospital grade cord with 'green dot' plug
Secure three-pronged cord for added unit safety
Manual defrost
Efficient performance with reliable temperature stability
-20º capable
Low temperature capability ideal for certain sensitive items
Pull-out drawers
Four clear baskets for convenient and separated storage
Adjustable thermostat
Rear mounted to prevent accidental adjustments
Flat door liner
Easy to clean, with more depth for storage
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals
Matching refrigerator available
Pair with FF521BL7SSHVADA for a complete ADA compliant set
