FS407L7MED
SHARE THIS PRODUCT
E-mail a Friend Print

SPECIFICATIONS

Overview
Height of Cabinet 33.5" (85 cm)
Height to Hinge Cap 34.0" (86 cm)
Width 19.25" (49 cm)
Depth 21.38" (54 cm)
Depth with Handle 23.0" (58 cm)
Depth with door at 90° 39.5" (100 cm)
Capacity 2.8 cu.ft. (79 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 1.6
Voltage/Frequency 115 V AC/60 Hz
Weight 64.0 lbs. (29 kg)
Shipping Weight 85.0 lbs. (39 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing RHD
Reversible Factory Reversible
Interior Height 26.38" (67 cm)
Interior Width 14.0" (36 cm)
Interior Depth 16.75" (43 cm)
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 3.0 oz.
High Side PSI 210.0
Low Side PSI 105.0
Level Legs 2
Interior Drawers Yes
Drawers Qty 4

AVAILABLE UPGRADES

Exterior
DL2 Temperature Logger
USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
SCD Self-Closing Door
Protect interior contents and reduce energy waste with the Self Closing Door Option
ODA Open Door Alarm
Add an open door alarm to audibly buzz when the door is left ajar.
LHD
Door reversal to left hand swing
Latch
Top-mounted door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
DT Digital Thermostat
Install a digital thermostat with external readout for precise temperature management
DL1 Temperature Logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Lock
KEYPAD
Battery-powered keypad lock installed for keyless security
KEY
Extra keys available for purchase
AC Keypad
Keypad lock powered by appliance power cord for keyless security


California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

FS407L7MED Matching refrigerator 1fb6556d9b0cb2e64cec9dc4031ce73c627b001b680e10e944813b0725db703e

Commercial meets nsf 57f181a562ef64be646d83b66028b1c5c2f384b45328a17b7b74a5f0cdc84c8e
This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

Slim 20" fit with interior basket drawers for optimum cold storage

34.0" H x 19.25" W x 21.38" D

OVERVIEW

WHERE TO BUY

Invalid Format
Accucold by Summit Appliance's FS407L7MED is a counter height all-freezer specially featured for use in medical and laboratory facilities.

At just 20" wide, this manual defrost all-freezer fits well in any setting. It can reach temperatures as low as -20º C and offers 2.8 cu.ft. of storage capacity. Four pull-out drawers with clear fronts offer convenient storage solutions and help to protect interior contents when the door is opened. The adjustable thermostat is located in the rear of the model and a hospital grade (green dot) cord offers additional safety in high traffic areas.

This model has a white exterior cabinet and door. A high temperature alarm with an external temperature readout is installed on the front and a top-mounted lock offers added security.

The FS407L7MED is designed for freestanding use and can be paired with the matching auto defrost FF511L7MED all-refrigerator. This model is ETL-S listed to commercial standards.

FEATURES

Slim 20" width
2.8 capacity inside a slim footprint
Commercially listed
ETL-S listed to NSF standards for commercial use
Fully finished white cabinet
Allows the unit to be used freestanding
Factory installed lock
Top-mounted for convenient security
High temperature alarm
Audio alarm signals temperature increases
External temperature readout
Alarm includes thermometer so users can read the temperature without opening the door
Hospital grade cord with 'green dot' plug
Secure three-pronged cord for added unit safety
Manual defrost
Efficient performance with reliable temperature stability
-20º capable
Low temperature capability ideal for certain sensitive items
Pull-out drawers
Four clear baskets for convenient and separated storage
Adjustable thermostat
Rear mounted to prevent accidental adjustments
Flat door liner
Easy to clean, with more depth for storage
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals
Matching refrigerator available
Pair with FF511L7MED for a complete set

DOWNLOADS

Download BROCHURE w/ DRAWINGS
FS407L7MED.pdf
Download TECHNICAL DRAWING (.dwg)
FS407L_FS408BLFRE.A-C2000.dwg
Download MSDS INFORMATION
R134a_MSDS_T.pdf
Download MSDS INFORMATION
PROPYLENE_GLYCOL_MSDS1.pdf
