22" Wide Top Mount Refrigerator-Freezer

SKU: FF946W
Made in North America with a unique footprint for smaller kitchens
Estimated Time to Ship:

Next day shipping

This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.
Add a naturally antimicrobial copper handle for added protection against germs and bacteria.
65.75" H x 22.0" W x 26.0" D
(167cm H x 56cm W x 66cm D)

Overview
Height of Cabinet 64.75" (164 cm)
Height to Hinge Cap 65.75" (167 cm)
Width 22.0" (56 cm)
Width with Door Open 23.75" (60 cm)
Depth 26.0" (66 cm)
Depth with door at 90° 44.25" (112 cm)
Capacity 8.8 cu.ft. (249 L)
Defrost Type Frost-Free
Door White
Cabinet White
US Electrical Safety UL
Canadian Electrical Safety ULC
Energy Usage/Year 316.0kWh/year
Amps 0.82
Voltage/Frequency 115 V AC/60 Hz
Weight 125.0 lbs. (57 kg)
Shipping Weight 134.5 lbs. (61 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101038445
Refrigerator-Freezer
Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Interior Light Yes
Refrigerator - Interior Height 40.5" (103 cm)
Refrigerator - Interior Width 17.0" (43 cm)
Refrigerator - Interior Depth 17.0" (43 cm)
Refrigerator - Capacity 6.67 cu.ft
Refrigerator - Shelf Type Glass
Refrigerator - Shelf Qty 2
Refrigerator - Full Door Shelves 4
Freezer - Interior Height 16.0" (41 cm)
Freezer - Interior Width 16.25" (41 cm)
Freezer - Interior Depth 13.25" (34 cm)
Freezer - Capacity 2.1 cu.ft
Freezer - Shelf Type Wire
Freezer - Shelf Qty 1
Freezer - Full Door Shelves 1
Freezer - Half Door Shelves 1
Thermostat Type Dial
Fan Type Interior
Refrigerant Type R134a
Refrigerant Amount 3.53 oz.
Level Legs 2
Compressor Step Height 9.75" (25 cm)
Compressor Step Width 17.0" (43 cm)
Compressor Step Depth 4.0" (10 cm)
Sound Level 34.3 dB

Handle
TB Set - Stainless steel towel bar handles pre-installed on unit
Professional towel bar style handles in brushed stainless steel, mounted vertically on select refrigerator-freezers (specify RHD or LHD)
TBC Copper Towel Bar Handles
Factory-installed towel bar handles made from pure copper for antimicrobial protection
CP Full-Length Copper Pipe Handles
Factory-installed full-length handles made from pure copper for antimicrobial protection
Lock
LL - Side-mounted locks
Add two side-mounted locks for separate access to each section
LLF2 - Combination lock
Single combination lock (with key override) secures both doors

Thin-line design

Limited space is no problem for our thin-line models, designed specifically for those hard-to-fit spots

Frost-free operation

No-frost convenience for reduced user maintenance

Adjustable shelves

Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Full freezer shelf

Offers additional options for organization

Door storage

Store large bottles right on the door for easy access

Clear crisper

Get the longest life and best taste out of produce by storing greens in a convenient slide drawer

Reversible doors

User-reversible door swing for added flexibility

Interior light

Automatically illuminates when you open the door

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

SUMMIT's thin-line collection of frost-free refrigerator-freezers brings quality and convenience to even the smallest kitchen space.

The FF946W offers a full 8.8 cu.ft. capacity inside a slim fit, with a unique curved door design for added style. The fresh food section includes adjustable glass shelves for spill-proof storage and easy cleaning, with a large tilt-out crisper and four door racks to help keep your refrigerator organized. The large freezer section includes a removable wire shelf and two door racks for added convenience.

Made in North America, the FF946W includes reversible doors and comes in a white finish. To add a factory installed icemaker, order FF946WIM. For this unit in stainless steel, see the FF948SS.

NOTE: Because of this unit's curved door style, the FF946W requires an additional 1 3/4" of width to open the doors to a full 90º. If placing this unit against a right angle wall, be sure to accommodate this extra space.

Download
BROCHURE w/ DRAWINGS
FF946W.pdf
Download
MSDS INFORMATION
MSDS_R134a_PS.pdf
Energy Guide

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
