24" Wide Built-In Craft Beer Pub Cellar

SKU: FF7LBLKPUBCSS

Made in Europe and customized for optimum storage of craft beer

DISCONTINUED

This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

34.0" H x 23.75" W x 23.5" D
(86cm H x 60cm W x 60cm D)

Overview
Height of Cabinet	33.5" (85 cm)
Height to Hinge Cap	34.0" (86 cm)
Width	23.75" (60 cm)
Depth	23.5" (60 cm)
Depth with Handle	25.25" (64 cm)
Depth with door at 90°	45.5" (116 cm)
Capacity	5.5 cu.ft. (156 L)
Defrost Type	Automatic
Door	Stainless Steel
Cabinet	Stainless Steel
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.4
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101073125
Wine Cellar
Number of Zones	1
Door Swing	RHD
Reversible	Factory Reversible
Adjustable Shelves	Yes
Shelf Type	Glass
Shelf Qty	3
Thermostat Type	Digital
Interior Light	Yes
Fan Type	Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.64 oz.
High Side PSI	180.0
Low Side PSI	80.0
Interior Height 1	27.75" (70 cm)
Interior Width 1	20.0" (51 cm)
Interior Depth 1	17.5" (44 cm)
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	20.0" (51 cm)
Compressor Step Depth	6.0" (15 cm)
Level Legs	4
Temperature Range	41º to 65ºF

Exterior

SSK - Stainless steel kickplate Stainless steel kickplate factory installed	Latch - Factory-installed door latch requires manual release to open unit Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles (NOTE: latch adds 1 1/2" of width to unit)
LHD - Left hand door swing Door reversal to left hand swing	SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option
SS Hinges Stainless steel top and bottom hinges	CAS3 3" casters 3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
Legs to raise unit height 6" high leveling legs

Lock

AC Keypad - AC powered keypad lock Keypad door lock powered by appliance power cord for keyless security	KEYPAD - Battery-powered keypad door lock Battery-powered keypad door lock installed for keyless security

Door

STO-Step-To-Open Door Pedal Step-to-open door pedal allows hands-free access to open the door 90 degrees

Commercially approved

ETL-S listed to NSF-7 Standards for use in commercial establishments

Designed for craft beer storage

Wide range temperature control lets you manage the interior between 41º and 65ºF for optimum storage of all types of beer

Slim undercounter dimensions

Less than 24 inches wide, with a generous 5.5 c.f. of storage capacity

Built-in capable

Make the best use of space by installing your appliance under the counter and flush with other cabinetry

Wrapped stainless steel exterior

Durable elegance built to last

Professional towel bar handle

A curved handle in brushed stainless steel provides generous room for a comfortable grip

Factory installed lock

Keyed lock for a secure interior

Digital thermostat

Exterior thermostat located in kickplate lets you manage the temperature without opening the door

Automatic defrost

Reduced maintenance with auto defrost system

Adjustable glass shelves

Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup

Flat door liner

An easy-to-clean flat liner accepts large trays

Deep shelf space

Interior can accommodate large trays up to 19 1/2" x 15 1/2"

One piece interior liner

Simple cleanup with a seamless liner that won't hold a mess in hidden crevices

Interior light on rocker switch

Turn the light on when you need it and off when you're done with a a convenient switch located behind the thermostat

Fully finished cabinet

Allows the unit to be used freestanding

100% CFC free

Environmentally friendly design does not contain ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

SUMMIT's unique selection of European Pub Cellars offer a smart solution to storing or aging craft beer at the proper temperature.

The FF7LBLKPUBCSS is ETL-S listed to NSF-7 standards for commercial use. The front-breathing system allows built-in installation, while the fully finished cabinet also enables freestanding use. At 24" wide and deep, this unit is ideally sized for any application. It features a stainless steel wrapped door cabinet and door, complete with a towel bar handle and factory installed lock.

Designed for optimum storage of craft beer, SUMMIT Pub Cellars include a digital thermostat preset at 45ºF, with a range between 41-65ºF to accommodate a wide range of brews. The FF7LBLKPUBCSS utilizes automatic defrost operation to ensure minimum user maintenance inside the 5.5 cu.ft. interior. Adjustable glass shelves offer convenient and spill-proof storage. This unit includes an interior light on a rocker on/off switch.

With its ideal footprint and quality design, the FF7LBLKPUBCSS makes it easy to keep craft beer stored at its best.

BROCHURE w/ DRAWINGS
FF7LBLKPUBCSS.pdf

TECHNICAL DRAWING (.dwg)
FF7LCSSPUB_FF7LBLCSSPUBFEFRIGERATORA-C2000.dwg

USE & CARE
Pub_Cellar_Manual.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
