SPECIFICATIONS

Overview
Height of Cabinet	32.0" (81 cm)
Height to Hinge Cap	32.25" (82 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Depth with Handle	25.13" (64 cm)
Depth with door at 90°	45.63" (116 cm)
Capacity	5.5 cu.ft. (156 L)
Defrost Type	Automatic
Door	Panel-Ready
Cabinet	White
US Electrical Safety	UL
Canadian Electrical Safety	ULC
Sanitation	ETL-S
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Shipping Weight	107.0 lbs. (49 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Refrigerator Features
Door Swing	RHD
Reversible	Yes
Crisper Qty	1
Crisper Finish	Opaque
Crisper Cover	Glass
Shelf Type	Wire
Shelf Qty	3
Full Door Shelf Qty	3
Adjustable Shelves	Yes
Thermostat Type	Dial
Fan Type	Exterior
Refrigerant Type	R134a
Refrigerant Amount	1.8oz.
High Side PSI	285.0
Low Side PSI	70.0
Level Legs Qty	4
Interior Light	Yes
Dimensions
Interior Height	27.75" (70 cm)
Interior Width	20.0" (51 cm)
Interior Depth	17.5" (44 cm)
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	20.0" (51 cm)
Compressor Step Depth	6.0" (15 cm)

AVAILABLE UPGRADES

Exterior

DL2 Temperature Logger USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout	TT Thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	DT Digital Thermostat Install a digital thermostat with external readout for precise temperature management
Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	KEY Extra keys available for purchase
SCD Self-Closing Door Protect interior contents and reduce energy waste with the Self Closing Door Option	ODA Open Door Alarm Add an open door alarm to audibly buzz when the door is left ajar.
LHD Door reversal to left hand swing	Latch Top-mounted door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
SSK Stainless steel kickplate factory installed	HUM Humidity Sensor Humidity sensor with min/max readout
HG Cord Add a hospital grade cord equipped with green dot plug with the HG suffix	DL1 Temperature Logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac

Lock

KEYPAD

Battery-powered keypad lock installed for keyless security

AC Keypad

Keypad lock powered by appliance power cord for keyless security

Interior

FCGP - Fan w/Gel Packs

Internal fan with gel packs included for a stabilized interior

FC - Internal Fan

Internal fan for even temperature distribution throughout the unit interior

California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

FF6LBI7FRADA

This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

Made in Europe and meets NSF-7 commercial standards

32.25" H x 23.63" W x 23.5" D

OVERVIEW

32 inch height fits under lower ADA compliant counters
Commercially approved for use in foodservice establishments
Stainless steel door frame accepts slide-in panels for a custom look
Flexible design allows built-in or freestanding use in 24" spaces
Factory-installed lock provides security you can count on
Automatic defrost ensures minimum user maintenance
Includes door storage and adjustable shelves
Full 5.5 cu.ft. capacity inside a convenient 24" footprint
Made in Europe

WHERE TO BUY

Accucold by Summit Appliance offers a wide range of all-refrigerators for general purpose storage. The commercially listed FF6BI7ADA Series features 24" wide all-refrigerators designed for built-in undercounter use in ADA compliant settings.

The FF6LBI7FRADA is a 32" high all-refrigerator with a full 5.5 cu.ft. capacity inside a slim 24" footprint. The front-breathing design allows built-in use under counters, while the fully finished cabinet also lets this unit be used freestanding. This model has a white cabinet. The user-reversible door includes a two-piece stainless steel frame to accept slide-in panels for a custom look (panel size: 23" W x 28" H at up to 1/4" thick). A stainless steel handle and factory installed front lock are included.

Inside, the FF6LBI7FRADA utilizes low maintenance automatic defrost operation. Our unique "hidden" evaporator is set behind the rear wall to create a seamless, easy-to-clean interior. Adjustable wire shelves allow users to reconfigure the interior for optimum storage. Additional features include automatic interior lighting, door storage, and a crisper drawer. This unit includes an adjustable dial thermostat.

The FF6LBI7FRADA is ETL-S listed to NSF-7 standards for use in commercial establishments. For more finish options, browse the entire FF6BI7ADA Series.

NOTE: This unit is designed for general purpose, medical, or commercial applications and does not meet DOE energy standards for residential use.

FEATURES

Commercially approved ETL-S listed to NSF-7 commercial standards	ADA compliant 32 inch height fits under standard ADA counters
Slim undercounter dimensions Less than 24 inches wide with a full 5.5 c.f. capacity	Built-in capable Make the best use of space by installing your appliance under the counter and flush with other cabinets
Fully finished white cabinet Allows the unit to be used freestanding	Factory installed lock Keyed lock offers added security
Stainless steel door frame Slide a panel into this two-piece U-shaped frame to match your unit to other cabinets (panel size: 23" W x 28" H at up to 1/4" thick)	Pro style handle Stainless steel handle can be reversed with door swing
Automatic defrost Reduced maintenance with auto defrost system	Hidden evaporator Cold wall design with hidden evaporator and seamless interior
One piece interior liner Easy clean-up with a seamless liner that won't hold a mess in hidden crevices	Adjustable shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
Door shelves Keep tall bottles and condiments right on the door for convenient access	Crisper Get the longest life and best taste out of produce by storing greens in a convenient slide drawer
Adjustable thermostat Dial thermostat located inside for easy temperature management	Interior light Automatically illuminates when you open the door
100% CFC free Environmentally friendly design without ozone-damaging chemicals
