24" Wide Built-In All-Refrigerator

SKU: FF61WBIFR

Door accepts slide-in panels for a custom look

DISCONTINUED- REPLACED BY FF61WIF

33.5" H x 23.63" W x 23.0" D
(85cm H x 60cm W x 58cm D)

Overview
Height of Cabinet	33.5" (85 cm)
Width	23.63" (60 cm)
Depth	23.0" (58 cm)
Depth with door at 90°	45.38" (115 cm)
Capacity	5.5 cu.ft. (156 L)
Defrost Type	Automatic
Door	Panel-Ready
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Energy Usage/Year	307.0kWh/year
Amps	1.4
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101070001
Refrigerator Features
Door Swing	RHD
Reversible	Yes
Crisper Qty	1
Crisper Finish	Opaque
Crisper Cover	Glass
Shelf Type	Glass
Shelf Qty	3
Full Door Shelf Qty	3
Adjustable Shelves	Yes
Wine Bottle Shelves	Yes
Thermostat Type	Dial
Fan Type	Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.64oz.
High Side PSI	180.0
Low Side PSI	80.0
Level Legs Qty	4
Interior Light	Yes
Dimensions
Interior Height	26.25" (67 cm)
Interior Width	21.0" (53 cm)
Interior Depth	18.0" (46 cm)
Compressor Step Height	5.5" (14 cm)
Compressor Step Width	21.0" (53 cm)
Compressor Step Depth	6.0" (15 cm)

Exterior

DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout	CAS3 3" casters 3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	Legs to raise unit height 6" high leveling legs
DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management	Alarm/Thermometer - Factory-installed alarm with external temperature readout Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option	LHD - Left hand door swing Door reversal to left hand swing
Latch - Factory-installed latch requires manual release to open unit (NOTE: adds 1 1/2" of width) Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles (NOTE: latch adds 1 1/2" of width to unit)	SSK - Stainless steel kickplate Stainless steel kickplate factory installed
HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix

Lock

L-SideLock Add a single keyed lock located on the door's side (NOTE: side lock adds 1" to overall unit width and comes in white)	KEYPAD - Battery-powered keypad door lock Battery-powered keypad door lock installed for keyless security
AC Keypad - AC powered keypad lock Keypad door lock powered by appliance power cord for keyless security

Interior

FCGP internal fan with gel packs Internal fan with gel packs included for a stabilized interior

Door

STO-Step-To-Open Door Pedal Step-to-open door pedal allows hands-free access to open the door 90 degrees

Slim undercounter dimensions

Less than 24" wide with a full 5.5 cu.ft. capacity

Built-in capable

Make the best use of space by installing your appliance under the counter and flush with other cabinets

Stainless steel door frame

Two-piece U-shaped door frame in stainless steel accepts slide-in panels (sized 23" W x 28" H at up to 1/4" thick), allowing users to create a custom look to match or complement adjacent cabinetry

Professional handle

Professional handle attached to door frame finishes the look

Automatic defrost

Reduced user maintenance with automatic defrost operation

Adjustable glass shelves

Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Fruit and vegetable crisper

Get the longest life and best taste out of produce by storing greens in a convenient slide drawer

Door storage

Keep tall bottles and condiments right on the door for convenient access

Wine shelf

Removable scalloped wine shelf is included to store champagne and wine bottles

Hidden evaporator

Cold wall design with hidden evaporator and seamless interior

One piece interior liner

Enjoy easy clean-up with a seamless liner that won't hold a mess in hidden crevices

Adjustable thermostat

Dial thermostat located inside for easy temperature management

Reversible door

User-reversible door swing for added flexibility

Fully finished cabinet

Allows the refrigerator to be used as a freestanding model

Height Adjustable

Adjustable legs allow the unit to be sized from 32 1/2" to 34" high

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

SUMMIT offers the industry’s largest selection of built-in undercounter refrigeration , with a range of choices to best suit any kitchen. The FF61BI Series includes European made all-refrigerators designed for built-in installation in residential settings.

Sized with a 24” footprint, the FF61WBIFR is front-breathing for built-in use. The fully finished cabinet also allows freestanding use for added versatility. The user-reversible door includes a two-piece stainless steel frame designed to accept slide-in panels, letting you customize your unit to best fit its setting (panel size: 23" W x 28" H at up to 1/4" thick). A sleek stainless steel handle is included. This model has a white cabinet.

The FF61WBIFR refrigerator utilizes automatic defrost operation to ensure minimum user maintenance. The 5.5 cu.ft. interior offers more storage space than most models in this size class. Adjustable glass shelves ensure spill-proof storage, while a large crisper drawer is ideal for keeping produce at its best. A removable wine shelf lets you keep bottles securely in place. The door includes three storage racks for condiments and tall bottles. The seamless interior also features a dial thermostat and automatic light.

Designed and constructed in Europe, the FF61WBIFR refrigerator offers reliable cold storage for any home looking to install a quality all-refrigerator under the counter. For additional finish options, browse the FF61BI Series.

BROCHURE
FF61WBIFR.pdf

USE & CARE
FF61WBI_FF63BKBI_Use___Care.pdf

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
