FF511LIF
SHARE THIS PRODUCT
E-mail a Friend Print

SPECIFICATIONS

Overview
Height to Cabinet 33.5"
Height to Hinge Cap 34.0"
Width 19.25"
Depth 21.38"
Depth with door at 90° 39.5"
Capacity 4.1 cu.ft.
Defrost Type Automatic
Door Panel-Ready
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Energy Usage/Year 406.0kWh/year
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 64.0 lbs.
Shipping Weight 85.0 lbs.
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Yes
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Shelf Type Wire
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 1.75oz.
High Side PSI 205.0
Low Side PSI 103.0
Level Legs Qty 2
Interior Light Yes
Dimensions
Interior Height 28.5"
Interior Width 15.75"
Interior Depth 18.0"
Compressor Step Height 8.0"
Compressor Step Width 17.0"
Compressor Step Depth 6.75"

AVAILABLE UPGRADES

Exterior
DL1 Temperature Logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
HUM Humidity Sensor
Humidity sensor with min/max readout
Latch
Top-mounted door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD
Door reversal to left hand swing
SCD Self-Closing Door
Protect interior contents and reduce energy waste with the Self Closing Door Option
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
CAS3 3" Casters
3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
CAS6 6" Casters
6" high NSF listed casters
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
TT Thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
Lock
KEY
Extra keys available for purchase
AC Keypad
Keypad lock powered by appliance power cord for keyless security
KEYPAD
Battery-powered keypad lock installed for keyless security
Interior
FC - Internal Fan
Internal fan for even temperature distribution throughout the unit interior
FCGP - Fan w/Gel Packs
Internal fan with gel packs included for a stabilized interior


California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

FF511LIF

DISCONTINUED- REPLACED BY FF511LBIIF

34.0" H x 19.25" W x 21.38" D

OVERVIEW

SUMMIT brings quality cooling to 20" spaces with FF511L series of counter height all-refrigerators with full auto defrost.

The FF511LIF features a full 4.1 cu.ft. capacity. This all-white refrigerator includes a reversible door with an easy-to-clean flat interior liner. An integrated door frame lets users mount full overlay panels for a true customized look, with a factory installed lock located at the top of the door for convenient security.

Inside, this auto defrost refrigerator includes three adjustable wire shelves. A bottom crisper drawer offers added storage options. Additional features include an adjustable thermostat and a switchable interior light.

At just 20" wide, the FF511LIF is ideal for any space in need of quality cooling and can be perfectly matched with our FS407LIF all-freezer. This model is designed for freestanding household use. For a built-in version of this model, see the FF511LBIIF.

FEATURES

Slim 20" width
Full 4.1 cu.ft. capacity inside conveniently slim footprint
Fully finished cabinet
Allows the unit to be used freestanding
Factory installed lock
Top-mounted for convenient security
Integrated door frame
Stainless steel door frame accepts overlay panels for users to create a custom look over the front (panel size: 19 1/2" W x 31 1/2" H and up to 3/4" thick)
Reversible door
Keep your options flexible with a reversible door that is easy to switch when your arrangement changes
Automatic defrost
Reduced maintenance with auto defrost system
Adjustable shelves
Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
Crisper drawer
Get the longest life and best taste out of produce by storing greens in a bottom crisper
Interior light
Turn the light on and off with a convenient rocker switch
Flat door liner
Easy to clean, with more depth for storage
Adjustable thermostat
Manage the temperature with ease and accuracy
Matching freezer available
Combine any FF511LIF with a matching FS407LIF for a complete counter height set
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals
