SPECIFICATIONS
Overview | |
---|---|
Height of Cabinet | 32.0" (81 cm) |
Height to Hinge Cap | 32.38" (82 cm) |
Width | 23.63" (60 cm) |
Depth | 23.5" (60 cm) |
Depth with Handle | 25.63" (65 cm) |
Depth with door at 90° | 45.63" (116 cm) |
Capacity | 5.1 cu.ft. (144 L) |
Defrost Type | Cycle |
Door | Stainless Steel |
Cabinet | White |
US Electrical Safety | UL |
Canadian Electrical Safety | ULC |
Amps | 1.3 |
Voltage/Frequency | 115 V AC/60 Hz |
Shipping Weight | 148.0 lbs. (67 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
Refrigerator-Freezer | |
Door Swing | RHD |
Reversible | Factory Reversible |
Adjustable Shelves | Yes |
Crisper Qty | 1 |
Crisper Finish | Transparent |
Crisper Cover | Wire |
Wine Bottle Shelving | Yes |
Interior Light | Yes |
Refrigerator - Interior Height | 19.5" (50 cm) |
Refrigerator - Interior Width | 20.5" (52 cm) |
Refrigerator - Interior Depth | 17.0" (43 cm) |
Refrigerator - Shelf Type | Glass |
Refrigerator - Shelf Qty | 3 |
Refrigerator - Full Door Shelves | 3 |
Freezer - Interior Height | 5.0" (13 cm) |
Freezer - Interior Width | 19.0" (48 cm) |
Freezer - Interior Depth | 11.5" (29 cm) |
Thermostat Type | Dial |
Fan Type | Exterior |
Refrigerant Type | R134a |
Refrigerant Amount | 2.6 oz. |
High Side PSI | 285.0 |
Low Side PSI | 70.0 |
Level Legs | 4 |
Compressor Step Height | 7.0" (18 cm) |
Compressor Step Width | 20.5" (52 cm) |
Compressor Step Depth | 5.0" (13 cm) |
AVAILABLE UPGRADES
Interior | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||
Exterior | ||||||||||
|
||||||||||
Lock | ||||||||||
|
California residents:
click here for information on Proposition 65
Due to our commitment to continuous product improvement, all specifications are subject to change without notice
CT67BISSHVADA
DISCONTINUED- REPLACED BY CT661BISSHVADA
32.38" H x 23.63" W x 23.5" D
OVERVIEW
- 32 inch height fits under lower ADA compliant counters
- Flexible design allows built-in or freestanding use
- Perfectly sized to fit under counters and in tight 24 inch spaces
- Stainless steel door complete with sleek vertical handle adds modern luxury to any setting
- Ice cream stays frozen in zero degree freezer
- Improved temperature performance with SUMMIT's dual evaporator cooling
SUMMIT's CT67BIADA series features refrigerator-freezers designed for quality cooling that fits under ADA compliant counters. The CT67BISSHVADA uses SUMMIT's own dual evaporator system to separately cool the freezer and fresh food sections. Cycle defrost helps to reduce user maintenance on the refrigerator while maintaining a zero degree freezer that keeps frozen food frozen. The deluxe interior is fully featured for convenient storage. Adjustable glass shelves let you organize your space, with door racks and a large crisper providing additional options. Interior lighting and an adjustable thermostat complete the package. At under 24 inches wide the CT67BISSHVADA fits well in locations with space limitations. The 32 inch height allows built-in installation under lower ADA compliant counters while the finished cabinet also allows freestanding use. The white cabinet is fitted with a fully wrapped stainless steel door. A sleek handle in stainless steel is included for added style. The CT67BI has long proven itself to have one of the best temperature performance records in the industry. With over five cubic feet of storage capacity, this model is leader in quality, reliability, and convenience.
FEATURES
ADA compliant 32 inch height fits under standard ADA counters |
Built-in capable Make the best use of space by installing your appliance under the counter and flush with other cabinets |
Fully finished white cabinet Allows the unit to be used freestanding |
Stainless steel door Durable design with lasting elegance |
Professional stainless steel handle Thin 14mm diameter on vertical stainless steel handle |
Cycle defrost Combines an automatic defrosting refrigerator with a manual defrost freezer to save unit energy and user maintenance |
Dual evaporator cooling SUMMIT's unique and efficient dual evaporator separately cools the refrigerator while maintaining zero degrees in the freezer |
Zero degree freezer Keep ice cream frozen and freezer burn-free in a freezer that reaches and maintains zero degrees |
Adjustable glass shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up |
Clear crisper Get the longest life and best taste out of produce by storing greens in a convenient slide drawer |
Door shelves Store large bottles right on the door for easy access |
Adjustable thermostat Manage the interior temperature with ease and accuracy |
Interior light Automatically illuminates when you open the door |
100% CFC free Environmentally friendly design without ozone-damaging chemicals |
