SPECIFICATIONS

Overview
Height of Cabinet	32.0" (81 cm)
Height to Hinge Cap	32.38" (82 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Capacity	5.1 cu.ft. (144 L)
Defrost Type	Cycle
Door	Stainless Steel
Cabinet	White
US Electrical Safety	UL
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Refrigerator-Freezer
Door Swing	RHD
Reversible	Factory Reversible
Adjustable Shelves	Yes
Crisper Qty	1
Crisper Finish	Transparent
Crisper Cover	Glass
Interior Light	Yes
Refrigerator - Shelf Type	Wire
Refrigerator - Shelf Qty	2
Refrigerator - Full Door Shelves	3
Thermostat Type	Dial
Refrigerant Type	R134a
Refrigerant Amount	2.6 oz.
High Side PSI	285.0
Low Side PSI	70.0

AVAILABLE UPGRADES

Interior

FCGP - Fan w/Gel Packs

Internal fan with gel packs included for a stabilized interior

FC - Internal Fan

Internal fan for even temperature distribution throughout the unit interior

Exterior

TT Thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order	PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices
Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	SS Hinges Stainless steel top and bottom hinges
SCD Self-Closing Door Protect interior contents and reduce energy waste with the Self Closing Door Option	ODA Open Door Alarm Add an open door alarm to audibly buzz when the door is left ajar.
LHD Door reversal to left hand swing	Latch Top-mounted door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
SSK Stainless steel kickplate factory installed	HUM Humidity Sensor Humidity sensor with min/max readout
HG Cord Add a hospital grade cord equipped with green dot plug with the HG suffix	DL1 Temperature Logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Agion Door Treat the door with Agion silver antimicrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface

Lock

KEY

Extra keys available for purchase

California residents:
click here for information on Proposition 65

Due to our commitment to continuous product improvement, all specifications are subject to change without notice

CT66LBISSTBADA

Unique dual evaporator system ensures better cooling in each section

32.38" H x 23.63" W x 23.5" D

OVERVIEW

32" height fits under lower ADA compliant counters
Flexible design allows built-in or freestanding use in 24" spaces
Factory installed lock offers security you can count on
Stainless steel wrapped door with professional towel bar handle adds luxury to any setting
Improved temperature performance with our unique dual evaporator cooling
Made in Europe

WHERE TO BUY

Accucold by Summit Appliance offers a wide range of undercounter refrigeration for general purpose storage. The CT66JBIADA Series includes refrigerator-freezers designed for optimum storage conditions in built-in applications under lower ADA compliant counters.

At 32" high, the CT66LBISSTBADA can be used built-in or freestanding in ADA compliant settings. The 24" footprint fits many popular cutouts while offering over 5 cu.ft. of storage capacity. This model has a white cabinet and stainless steel wrapped door with a factory installed lock. A curved towel bar handle completes the professional look.

Inside, our unique dual evaporator system separately cools the refrigerator and freezer sections to ensure proper storage temperature. Cycle defrost operation reduces user maintenance in the automatic defrost fresh food section, with static manual defrost operation in the freezer compartment. Door storage provides easy access for tall bottles and small condiments. Additional features include adjustable shelves, a clear crisper, and automatic interior lighting.

The CT66LBISSTBADA has long proven itself to have one of the best temperature performance records in the industry. To see additional finish options on this unit, browse the full CT66JBIADA Series.

NOTE: This unit is designed for general purpose, medical, or commercial applications and does not meet DOE energy standards for residential use.

FEATURES

ADA compliant 32" high to fit under lower ADA compliant counters	Slim undercounter dimensions Less than 24" wide with a generous storage capacity
Built-in capable Make the best use of space by installing your appliance under the counter	Fully finished white cabinet Allows the unit to be used freestanding
Factory installed lock Keyed security on the refrigerator door	Stainless steel door Durable 304 grade wrapping
Professional towel bar handle Curved handle in brushed stainless steel offers a sturdy grip with professional elegance	Cycle defrost This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
Dual evaporator Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators	Adjustable shelves Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
Door storage Keep tall bottles and condiments right on the door for convenient access	Clear crisper drawer Get the longest life and best taste out of produce by storing greens in a bottom crisper
Interior light Automatically illuminates when you open the door	Adjustable thermostat Dial thermostat located inside for easy temperature management
100% CFC Free Environmentally friendly design with no ozone-damaging chemicals
