29" Wide Top Mount Refrigerator-Freezer With Icemaker

SKU: FF1620WSSTBIM
DISCONTINUED- REPLACED BY FF1512SSIM
69.13" H x 29.38" W x 27.88" D
(176cm H x 75cm W x 71cm D)

Overview
Height of Cabinet 69.13" (176 cm)
Width 29.38" (75 cm)
Depth 27.88" (71 cm)
Depth with Handle 30.38" (77 cm)
Depth with door at 90° 54.63" (139 cm)
Capacity 15.8 cu.ft. (447 L)
Defrost Type Frost-Free
Door Stainless Steel
Cabinet White
US Electrical Safety UL
Canadian Electrical Safety ULC
Energy Usage/Year 457.0kWh/year
Amps 3.0
Voltage/Frequency 115 V AC/60 Hz
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator-Freezer
Door Swing RHD
Reversible Factory Reversible
Adjustable Shelves Yes
Crisper Qty 2
Crisper Finish Transparent
Crisper Cover Glass
Interior Light Yes
Refrigerator - Interior Height 38.75" (98 cm)
Refrigerator - Interior Width 25.0" (64 cm)
Refrigerator - Interior Depth 22.25" (57 cm)
Refrigerator - Shelf Type Glass
Refrigerator - Shelf Qty 2
Refrigerator - Full Door Shelves 7
Freezer - Interior Height 19.63" (50 cm)
Freezer - Interior Width 24.5" (62 cm)
Freezer - Interior Depth 17.0" (43 cm)
Gallon Door Storage Yes
Thermostat Type Dial
Fan Type Interior
Refrigerant Type R134a
Refrigerant Amount 3.5 oz.
High Side PSI 335.0
Low Side PSI 140.0
Level Legs 2
Wheels 4

Exterior
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Alarm/Thermometer - Factory-installed alarm with external temperature readout
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Stainless steel wrapped doors

Durable 304 grade wrapping

Professional towel bar handles

Curved stainless steel handles provide generous room for a comfortable grip

Factory installed icemaker

Forget the plastic trays and enjoy the convenience of ready-made ice in your freezer

Frost-free operation

No-frost convenience for reduced user maintenance

Adjustable glass shelves

Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup

Two clear crispers with humidity control

Get the longest life and best taste out of produce by storing greens in convenient slide drawers

Door storage

Store items right on the door for easy access

Hanging deli crisper

Mini-drawer suspends from a refrigerator shelf and can be adjusted from side to side

Full freezer shelf

Removable shelf for added convenience

Interior light

Automatically illuminates when you open the door

Adjustable thermostat

Manage the temperature with ease and accuracy

100% CFC Free

Environmentally friendly design with no ozone-damaging chemicals

SUMMIT carries one of the industry's best selections of frost-free refrigerator-freezers, with unique sizes for all kitchens and superior construction for years of reliable service.

The FF1620WSSTBIM has a white cabinet with 304 grade stainless steel wrapped doors for each section. Both include curved handles in brushed steel to complete the professional look.

This frost-free unit features a full 15.8 cu.ft. of storage inside a fully featured interior. Both the refrigerator and freezer sections include door racks and adjustable glass shelves. Two clear crispers give you more options when storing produce, with an extra mini-crisper that can be suspended and adjusted side to side hanging from one of the shelves. A factory installed icemaker offers added user convenience.

With its unique dimensions and thoughtful design, SUMMIT FF1620WSSTBIM makes a luxurious addition to any home kitchen. This model can alternatively be ordered with thin "HV" handles. You can also customize this refrigerator-freezer by choosing your own custom color for the doors and handles.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
