WNM2307DK
WNM2307DK
Open
Angle
SHARE THIS PRODUCT
Pinterest E-mail a Friend Print

SPECIFICATIONS

Overview
Height 44.0"
Width 30.0"
Depth 24.0"
Door Black
Cabinet White
Weight 170.0 lbs.
Shipping Weight 185.0 lbs.
Parts & Labor Warranty 1 Year
Gas Range
Ignition Spark
LP Convertible With KitLP Accessory
Oven Capacity 3.7cu.ft
Cooktop Surface Porcelain
Burner Type Open
Number of Burners 4
Burner #1 BTU 9000.0
Burner #2 BTU 9000.0
Burner #3 BTU 9000.0
Burner #4 BTU 9000.0
Burner Controls Dial
Oven Controls Dial
Oven Light Yes
Cooking Timer Yes
Backguard Yes
Backguard Display Yes
Oven Window Yes
Oven Interior Height 14.0"
Oven Interior Width 24.0"
Oven Interior Depth 19.0"
Broiler Location Below Oven
Broiler Door White
Oven Door Black Glass

AVAILABLE UPGRADES

Exterior
LP Conversion
Have this range factory converted to LP gas. KIT LP is included

WNM2307DK

Delivery
This product qualifies for next day delivery to areas within our trucking radius and next day shipping nationwide.

Made in the USA

44" H x 30" W x 24" D

OVERVIEW

WHERE TO BUY

Invalid Format
SUMMIT offers a wide selection of household ranges with high quality construction at superior value.

The WNM2307DK is a deluxe model with full features and a large oven for family meals. The 30" width fits well in apartments and houses with limited space.

Fully equipped for stress-free cooking, the WNM2307DK includes a digital clock and timer. A lower broiler drawer allows for even crisping and the see-through oven window with light lets you keep an eye on your baking. A durable yet elegant porcelain construction makes this unit a wise investment in value and luxury.

FEATURES

Electronic ignition
Gas spark ignition for automatic lighting of burners
Gas range
Natural gas range; can be converted to LP Gas in our shop or ordered with KIT LP for conversion
Porcelain construction
Solid porcelain range top and oven
Oven window and light
Provides a convenient and full-lit view of oven contents
Broiler drawer
Lower compartment for separate broiling with even heat distribution
Broiler pan included
Two-piece porcelain broiler tray with grease well
Recessed oven door
Smart design limits the depth and protects adjacent cabinets
Deluxe backguard
High backguard to protect wall from back splashes
Digital clock and timer
Backguard includes time readout
Removable black door
Black glass door can be removed during cleanup
Anti-tip bracket
Install to prevent accidents from tipping oven over

DOWNLOADS

Download BROCHURE
WNM2307DK.pdf

YOU MIGHT NEED

SS Grates

Quick View

SS Grates


Continuous stainless steel grates to fit SUMMIT gas ranges

Kit LP

Quick View

Kit LP


Kit to convert SUMMIT natural gas range or cooktop into LP gas

$15
