24" Wide Built-In Wine Cellar

SKU: SWC6GBLBIHV
ETL-S listed to NSF-7 standards for use in commercial settings
DISCONTINUED- REPLACED BY SWC532BLBIST
This unit can be used for commercial or residential applications. It meets applicable U.S. Department of Energy (DOE) standards for both household and commercial energy usage. For information on its commercial sanitation listing, see Specifications.
33.5" H x 23.63" W x 23.5" D
(85cm H x 60cm W x 60cm D)

Overview
Height of Cabinet 33.5" (85 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Capacity 5.5 cu.ft. (156 L)
Bottles 36 bottles
Defrost Type Automatic
Door Glass
Cabinet Black
US Electrical Safety UL
Canadian Electrical Safety ULC
Sanitation ETL-S
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 115.0 lbs. (52 kg)
Shipping Weight 135.5 lbs. (61 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101042732
Wine Cellar
Number of Zones 1
Door Swing RHD
Reversible Factory Reversible
Adjustable Shelves Yes
Shelf Type Scalloped
Shelf Qty 4
Thermostat Type Dial
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 0.67 oz.
High Side PSI 124.0
Low Side PSI 30.0
Interior Height 1 26.0" (66 cm)
Interior Width 1 20.75" (53 cm)
Interior Depth 1 17.5" (44 cm)
Compressor Step Height 6.0" (15 cm)
Compressor Step Width 20.75" (53 cm)
Compressor Step Depth 5.0" (13 cm)
Level Legs 4
Condensor Location Rear of Unit

Exterior
SSK - Stainless steel kickplate
Stainless steel kickplate factory installed
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
Alarm/Thermometer - Factory-installed alarm with external temperature readout
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
CAS3 3" casters
3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
DT - Digital thermostat
Install a digital thermostat with external readout for precise temperature management
Legs to raise unit height
6" high leveling legs
Door
T1 Door Tint
Tinted door in low-E mirror finish for maximum energy savings
T1S Door Tint
Reflective door tint in dark smoke finish for maximum energy savings
T2 Door Tint
Tinted door in reflective deep blue finish with high energy savings
T3 Door Tint
Reflective door tint in light blue finish for medium energy savings
T4 Door Tint
Neutral door tint in light smoke finish for moderate energy savings

Commercially approved

ETL-S listed to NSF-7 for use in foodservice establishments

Built-in capable

Make the best use of space by installing your appliance under the counter and flush with other cabinets

Fully finished black cabinet

Allows the unit to be used freestanding

Double pane tempered glass door

Display your collection behind a solid glass door trimmed in elegant brushed aluminum for a refined touch

Slim undercounter dimensions

Less than 24" wide to fit tight spaces

Professional handle

Thin handle with 14mm diameter mounted vertically

Factory installed lock

Keyed lock for secure interior, conveniently located at the top of the door

Automatic defrost

Reduced maintenance with auto defrost system

Internal fan

Fan-forced cooling helps to maintain a more evenly cooled interior

Scalloped steel shelving

Curved shelves designed for the ideal storage of wine bottles

Half-sized wire shelf

Sits on top of the compressor and features wire slots ideal for holding bottles on their sides

Interior light

Illuminate your collection with an interior light controlled by a rocker on/off switch

Hidden evaporator

SUMMIT's original "hidden" evaporator is concealed in the wall so it never touches your fingers or food

Adjustable thermostat

Dial thermostat accommodates white wine temperature. If using this model for red wine storage, add a DT digital thermostat upon ordering

100% CFC Free

Environmentally friendly design

Temperature range

5ºC to 10ºC/41ºF to 50ºF; To reach warmer temperatures, order with our red wine digital thermostat option (10ºC to 18ºC/50ºF to 64ºF range)

SUMMIT SWC6GBI series features European designed, commercially approved wine cellars capable of built-in use under counters.

The SWC6GBLBIHV is conveniently sized at just 24" wide, with a front-breathing design for built-in installation under counters. The fully finished black cabinet also allows freestanding use. This unit features a double pane tempered glass door for reliable storage and a professional handle in brushed stainless steel. The lock is located towards the top of the door for easier access.

Inside, the SWC6GBLBIHV includes adjustable scalloped shelves perfectly designed to hold bottles in place. The white interior helps to improve visibility, letting your collection stand out clearly. This unit includes an interior light with an on/off rocker switch located behind the adjustable dial thermostat.

The SWC6GBLBIHV is made in Europe and is ETL-S listed to NSF-7 standards for commercial use. Additional handle styles and door tint options are aviailable.

NOTE: These models are designed primarily for white wine storage but can be upgraded with a digital thermostat to accommodate red wine temperatures.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
