BI605 Series
SHARE THIS PRODUCT
E-mail a Friend Print

SPECIFICATIONS

Overview
Height 46.0"
Width 18.75"
Depth 18.63"
Capacity 3.9 cu.ft.
Defrost Type Manual
Door White
Cabinet White
Weight 110.0 lbs.
Shipping Weight 145.0 lbs.
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Microwave-Refrigerator
Refrigerator Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Shelf Type Wire
Shelf Qty 3
Full Door Shelves 3
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 2.1 oz.
High Side PSI 250.0
Low Side PSI 103.0
Refrigerator Interior Height 23.5"
Refrigerator Interior Width 16.5"
Refrigerator Interior Depth 14.5"
Freezer Interior Height 4.75"
Freezer Interior Width 15.0"
Freezer Interior Depth 11.0"
Compressor Step Height 7.5"
Compressor Step Width 23.5"
Compressor Step Depth 6.5"
Level Legs 2
Microwave Controls Digital
Specialized Cooking Buttons Yes

AVAILABLE UPGRADES

Exterior
LHD
Door reversal to left hand swing
Latch
Top-mounted door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations

MRF40

DISCONTINUED

46" H x 18.75" W x 18.63" D

OVERVIEW

WHERE TO BUY

Invalid Format
SUMMIT offers the industry's widest variety of refrigerator-microwave combination units, with sizes that fit your space and designs to serve your needs.

Model MRF40 combines a mid-sized microwave with SUMMIT's popular compact CM40WH refrigerator-freezer. The complete unit has a conveniently slim under 19" width for an easy fit in any tight spot. A reversible door with door storage for large bottles adds placement flexibility.

Enjoy savings in both energy and price with manual defrost operation that maintains stable temperature throughout the interior. Additional features include an adjustable thermostat, adjustable shelves and more

The MRF40's top unit contains variable functions and power settings for quality microwave cooking. All of SUMMIT's combination refrigerator-microwaves are shipped fully assembled and ready to use. Plug the microwave, refrigerator-freezer, and a third appliance (such as a coffee maker) into our power allocator box and use its cord for safe one-plug operation. This system protects your circuit breaker and power line by limiting overall power use to 10 amps.

In addition to those models listed in our MRF series, SUMMIT can custom-build refrigerator-microwave combination units to your individual specifications. Contact us today for more information.

FEATURES

Thin-line design
Limited space is no problem for our thin-line models, designed specifically for those hard-to-fit spots
CM40WH refrigerator-freezer
Manual defrost compact unit with adjustable shelves and door storage
SM900WH microwave oven
Touchpad mid-sized microwave with one-touch cook options and variable controls
Allocator box
Plug the refrigerator-freezer, microwave, and a third appliance into this allocator box for safe operation that limits total power consumption to 10 amps
Ships fully assembled in one box
No assembly required before use
Reversible door
User reversible door swing on CM40WH refrigerator

DOWNLOADS

Download TECHNICAL DRAWING (.dwg)
MRF40BFEFRIGERATOR_FREEZERS...
