FS407LBI7SSHV
SHARE THIS PRODUCT
Pinterest E-mail a Friend Print

SPECIFICATIONS

Overview
Height 33.5"
Height to Hinge Cap 34.0"
Width 19.25"
Depth 21.38"
Depth with door at 90° 39.5"
Capacity 2.8 cu.ft.
Defrost Type Manual
Door Stainless Steel
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Energy Usage/Year 298.0kWh/year
Amps 1.6
Voltage/Frequency 115 V AC/60 Hz
Weight 64.0 lbs.
Shipping Weight 85.0 lbs.
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Freezer
Door Swing RHD
Reversible Factory Reversible
Height Adjustable 1
Interior Height 26.38"
Interior Width 14.0"
Interior Depth 16.75"
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 3.0
High Side PSI 210.0
Low Side PSI 105.0
Level Legs 2
Interior Drawers Yes
Drawers Qty 4

AVAILABLE UPGRADES

Exterior
SCD Self-Closing Door
Protect interior contents and reduce energy waste with the Self Closing Door Option

FS407LBI7SSHV Matching refrigerator

Commercial approved
This unit meets NSF standards and is designed for commercial use. It complies with the U.S. Department of Energy (DOE) standards for commercial energy usage, but may not meet DOE household standards. For information on its commercial sanitation listing, see Specifications.

33.5" H x 19.25" W x 21.38" D

OVERVIEW

WHERE TO BUY

Invalid Format
AccuCold by Summit Appliance's FS407LBI7 Series features a quality selection of 20" wide commercial all-freezers for built-in installation under counters.

The ETL-S listed FS407LBISSHV is a manual defrost all-freezer with 2.8 cu.ft. capacity. Four pull-out drawers with clear fronts offer convenient storage solutions. The adjustable thermostat is located in the rear of the model and a hospital grade (green dot) cord offers additional safety in high traffic areas.

Designed for built-in or freestanding use, the FS407LBI7SSHV has a white cabinet with a professional style stainless steel wrapped door and sleek handle. A top-mounted lock adds convenient security.

Sized just under 20" wide, the FS407LBI7SSHV can be paired with the matching auto defrost FF511LBI7SSHV all-refrigerator.

FEATURES

Slim 20" width
2.8 capacity inside a slim footprint
Commercially listed
ETL-S listed to NSF standards for commercial use
Built-in capable
Make the best use of space by installing your appliance under the counter
Fully finished white cabinet
Allows the unit to be used freestanding
Factory installed lock
Top-mounted for convenient security
Stainless steel wrapped door
Durable 304 grade wrapping
Professional handle
Thin 14mm diameter on vertical stainless steel handle
Hospital grade cord with 'green dot' plug
Secure three-pronged cord for added unit safety
Manual defrost
Efficient performance with reliable temperature stability
-20º capable
Low temperature capability ideal for certain sensitive items
Pull-out drawers
Four clear baskets for convenient and separated storage
Adjustable thermostat
Rear mounted to prevent accidental adjustments
Flat door liner
Easy to clean, with more depth for storage
Matching refrigerator available
Pair with FF511LBI7SSHV for a complete undercounter set
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals

DOWNLOADS

Energy Guide
