SPECIFICATIONS

Overview
Height 32.0"
Height to Hinge Cap 32.5"
Width 19.25"
Depth 21.38"
Depth with door at 90° 39.5"
Capacity 4.1 cu.ft.
Defrost Type Automatic
Door Panel-Ready
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Energy Usage/Year 406.0kWh/year
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 64.0 lbs.
Shipping Weight 85.0 lbs.
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Yes
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Shelf Type Wire
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 1.75
High Side PSI 205.0
Low Side PSI 103.0
Level Legs Qty 2
Interior Light Yes
Dimensions
Interior Height 28.5"
Interior Width 15.75"
Interior Depth 18.0"
Compressor Step Height 8.0"
Compressor Step Width 17.0"
Compressor Step Depth 6.75"

AVAILABLE UPGRADES

Lock
KEYPAD
Battery-powered keypad lock installed for keyless security
KEY
Extra keys available for purchase
AC Keypad
Keypad lock powered by appliance power cord for keyless security
Interior
FCGP - Fan w/Gel Packs
Internal fan with gel packs included for a stabilized interior
FC - Internal Fan
Internal fan for even temperature distribution throughout the unit interior
Exterior
TT Thermometer
ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
SCD Self-Closing Door
Protect interior contents and reduce energy waste with the Self Closing Door Option
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
LHD
Door reversal to left hand swing
Latch
Top-mounted door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
HUM Humidity Sensor
Humidity sensor with min/max readout
DL1 Temperature Logger
USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
Alarm
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations

FF511LIFADA Matching freezer

DISCONTINUED- REPLACED BY FF511LBIIFADA

32" H x 19.25" W x 21.38" D

OVERVIEW

WHERE TO BUY

Invalid Format
SUMMIT brings quality cooling to 20" spaces with FF511LADA series of freestanding auto defrost all-refrigerators, specially sized at 32" high to comply with ADA guidelines.

The FF511LIFADA features a full 4.1 cu.ft. capacity. This all-white refrigerator includes a reversible door with an easy-to-clean flat interior liner. An integrated door frame lets users mount full overlay panels for a true customized look, with a factory installed lock located at the top of the door for convenient security.

Inside, this auto defrost refrigerator includes three adjustable wire shelves. A bottom crisper drawer offers added storage options. Additional features include an adjustable thermostat and a switchable interior light.

At just 20" wide, the ADA compliant FF511LIFADA is ideal for any space in need of reliable refrigeration and can be perfectly matched with our FS407LIFADA all-freezer. This model is designed for freestanding household use. For a built-in version of this model, see the FF511LBIIFADA.

FEATURES

ADA compliant
32" high meets ADA guidelines
Slim 20" width
Full 4.1 cu.ft. capacity inside conveniently slim footprint
Fully finished white cabinet
Allows the unit to be used freestanding
Integrated door frame
Stainless steel door frame accepts overlay panels for users to create a custom look over the front (panel size: 19 1/2" W x 31 1/2" H and up to 3/4" thick)
Reversible door
Keep your options flexible with a reversible door that is easy to switch when your arrangement changes
Factory installed lock
Top-mounted for convenient security
Automatic defrost
Reduced maintenance with auto defrost system
Adjustable shelves
Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
Crisper drawer
Get the longest life and best taste out of produce by storing greens in a bottom crisper
Interior light
Turn the light on and off with a convenient rocker switch
Flat door liner
Easy to clean, with more depth for storage
Adjustable thermostat
Manage the temperature with ease and accuracy
Matching freezer available
Combine any FF511LIFADA with a matching FS407LIFADA for a complete counter height set
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals

DOWNLOADS

Download BROCHURE
FF511LIFADA.pdf
Energy Guide
