20" Wide Built-In All-Refrigerator, ADA Compliant

SKU: FF511LBI7MEDDT
Digital thermostat for more precision in temperature management
DISCONTINUED- REPLACED BY ARS3PV
This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.
34.0" H x 19.25" W x 21.38" D
(86cm H x 49cm W x 54cm D)

Overview
Height of Cabinet 33.75" (86 cm)
Height to Hinge Cap 34.0" (86 cm)
Width 19.25" (49 cm)
Depth 21.38" (54 cm)
Depth with Handle 23.0" (58 cm)
Depth with door at 90° 39.5" (100 cm)
Capacity 4.1 cu.ft. (116 L)
Defrost Type Automatic
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 64.0 lbs. (29 kg)
Shipping Weight 85.0 lbs. (39 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101035338
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Height Adjustable 1
Shelf Type Wire
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior
Refrigerant Type R134a
Refrigerant Amount 1.75oz.
High Side PSI 205.0
Low Side PSI 103.0
Level Legs Qty 2
Interior Light Yes
Temperature Range 34ºF to 46ºF
Dimensions
Interior Height 28.5" (72 cm)
Interior Width 15.75" (40 cm)
Interior Depth 18.0" (46 cm)
Compressor Step Height 8.0" (20 cm)
Compressor Step Width 17.0" (43 cm)
Compressor Step Depth 6.75" (17 cm)

Exterior
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Commercially listed

ETL-S listed to NSF standards for commercial use

Slim 20" width

Full 4.1 cu.ft. capacity inside conveniently slim footprint

Built-in capable

Make the best use of space by installing your appliance under the counter

Fully finished white cabinet

Allows the unit to be used freestanding

Factory installed lock

Keyed lock for secure interior

Automatic defrost

Reduced maintenance with auto defrost system

Internal fan with heat sink

Fan-forced cooling ensures the unit is evenly cooled from top to bottom

Digital thermostat

Electronic controls for more precise temperature management

High temperature alarm

Warns of temperature fluctuations and includes an external temperature readout on the door

Hospital grade cord with 'green dot' plug

Secure three-pronged cord for added unit safety

Access port

Unit comes with a factory installed probe hole for users to connect their own monitoring equipment

Adjustable shelves

Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup

Flat door liner

Easy to clean, with more depth for storage

Interior light

Turn the light on and off with a convenient rocker switch

100% CFC Free

Environmentally friendly design with no ozone-damaging chemicals

Accucold by Summit introduces the MEDDT Series all-refrigerators with advanced features for use in medical, scientific, pharmaceutical, and laboratory institutions.

The FF511LBI7MEDDT is a 20" wide all-refrigerator designed for built-in use under counters. It uses automatic defrost operation complete with an internal fan and heat sink for even cold air distribution throughout the 4.1 cu.ft. interior. The door includes a front lock and high temperature warning alarm that also displays the current and high/low temperatures. A digital thermostat offers more control in temperature management. Additional features include an interior light, adjustable shelves, and hospital grade cord with a 'green dot' plug for added safety in high traffic areas.

The FF511LBI7MEDDT can be used built-in or freestanding and paired with the matching FS407LBI7MEDDT all-freezer. This unit is ETL-S listed for commercial use.

NOTE: The location of the digital thermostat can be adjusted according to customer needs. Please specify upon ordering whether you would like it installed inside the refrigerator, on top of the refrigerator, or on the side of the refrigerator (add 1 3/4" to the width). If no location is specified, the thermostat will be installed on the top.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
