24" Wide Built-In Refrigerator-Freezer

SKU: CT66LBIPLUS
Made in Europe with a unique dual evaporator system to ensure better cooling in each section
DISCONTINUED
33.5" H x 23.63" W x 23.5" D
(85cm H x 60cm W x 60cm D)

Overview
Height of Cabinet 33.5" (85 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Depth with Handle 25.13" (64 cm)
Depth with door at 90° 46.25" (117 cm)
Capacity 5.1 cu.ft. (144 L)
Defrost Type Cycle
Door White
Cabinet White
US Electrical Safety UL
Canadian Electrical Safety ULC
Amps 1.3
Shipping Weight 104.0 lbs. (47 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101035178
Refrigerator-Freezer
Door Swing RHD
Reversible Factory Reversible
Adjustable Shelves Yes
Interior Light Yes
Refrigerator - Interior Height 19.5" (50 cm)
Refrigerator - Interior Width 20.5" (52 cm)
Refrigerator - Interior Depth 17.0" (43 cm)
Refrigerator - Shelf Type Wire
Refrigerator - Shelf Qty 2
Refrigerator - Full Door Shelves 3
Freezer - Interior Height 5.0" (13 cm)
Freezer - Interior Width 19.0" (48 cm)
Freezer - Interior Depth 11.5" (29 cm)
Thermostat Type Dial
Fan Type Interior and Exterior
Refrigerant Type R134a
Refrigerant Amount 2.6 oz.
High Side PSI 285.0
Low Side PSI 70.0
Level Legs 4
Compressor Step Height 7.0" (18 cm)
Compressor Step Width 20.5" (52 cm)
Compressor Step Depth 5.0" (13 cm)

Exterior
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
SSK - Stainless steel kickplate
Stainless steel kickplate factory installed
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
SCD - Self-closing door
Protect interior contents and reduce energy waste with the Self Closing Door Option
Alarm/Thermometer - Factory-installed alarm with external temperature readout
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
Legs to raise unit height
6" high leveling legs
CAS3 3" casters
3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad - AC powered keypad lock
Keypad door lock powered by appliance power cord for keyless security
KEYPAD - Battery-powered keypad door lock
Battery-powered keypad door lock installed for keyless security
Door
STO-Step-To-Open Door Pedal
Step-to-open door pedal allows hands-free access to open the door 90 degrees

Built-in capable

Make the best use of space by installing your appliance under the counter

Factory installed lock

Keyed lock for secure interior

Thermometer

Thermometer provides external readout of current and high/low temperatures

Internal fan with heat sink

Fan-forced cooling helps the unit stay evenly cooled from top to bottom

Cycle defrost

This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment

Dual evaporator cooling

Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators

Adjustable shelves

Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup

Door storage

Store items right on the door for easy access

Access port

Unit comes with a factory installed probe hole for users to connect their own monitoring equipment

Adjustable thermostat

Manage the temperature with ease and accuracy

Fully finished white cabinet

Allows the unit to be used freestanding

Height Adjustable

Adjustable legs allow the unit to be sized from 33 1/2" to 34 3/4" high

100% CFC Free

Environmentally friendly design with no ozone-damaging chemicals

Accucold's PLUS Series refrigerator-freezers come specially featured use doctors’ offices, medical clinics, nursing stations, and other general purpose facilities that require more temperature assurance than a standard refrigeration unit provides.

The CT66LBIPLUS is a 24" wide 5.1 cu.ft. refrigerator-freezer with a front-breathing design for built-in installation. It uses our unique dual evaporator system to separately cool the refrigerator and freezer section, with cycle defrost (automatic refrigerator and manual freezer) for added efficiency.  An internal fan and heat sink help to keep the interior evenly cooled. The door includes a NIST thermometer that displays the current and high/low temperatures, as well as a factory installed top-mounted lock. Additional features include adjustable shelves, door storage, and an access port for user-installed monitoring equipment.

This 32" high model is designed for built-in use but can also be used freestanding. You can further customize this unit with a variety of features, including our USB temperature logger, self-closing door, open door alarm, and much more.

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
